Product Details
Description
The DO828 3BSE069055R1 is a 16-channel AC output module with two isolated groups of eight, each channel rated for 0.5 A. It uses solid-state switching, mounts on an MTU via ModuleBus, and supports hot-swapping for maintenance without interrupting continuous process operations.
Specifications
-
Manufacturer: ABB
-
Country of Origin: Switzerland
-
Model Number: DO828 (3BSE069055R1)
-
Product Type: Digital Output Module
-
Number of Channels: 16 (2 isolated groups of 8)
-
Rated Output Voltage: 120 V AC
-
Voltage Range: 77 V to 132 V AC
-
Max. Continuous Current: 0.5 A per channel
-
Switching Type: AC (Solid State)
-
Isolation: Group-to-group and group-to-logic isolation
-
Interface: S800 ModuleBus
-
Weight: 0.30 kg
Features
-
High-Density 120V AC Control: Consolidates 16 AC output channels in a single module, significantly reducing the footprint in control cabinets and power distribution panels.
-
Dual-Group Galvanic Isolation: Features two independent groups of eight channels, ensuring that electrical disturbances are contained and do not affect the entire module.
-
Robust Solid-State Design: Provides a long operational lifespan with consistent switching performance, free from the mechanical wear associated with traditional relay contacts.
-
Efficient Process Maintenance: Fully supports hot-swap functionality, enabling module exchange under power to ensure uninterrupted operation of critical process loops.
-
Integrated Hardware Diagnostics: Front-panel LED indicators provide real-time status for each channel and immediate notification of internal module faults.
-
Optimized for S800 Ecosystem: Designed for native integration with System 800xA, offering deterministic communication and simplified configuration via the ModuleBus.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
