Description
The DO815 3BSE013258R1 is an 8-channel digital output module with a single isolated common, delivering up to 2 A per channel. It features short-circuit and over-temperature protection, mounts on an MTU via ModuleBus, and supports hot-swapping for maintenance without powering down the system.
Specifications
-
Manufacturer: ABB
-
Country of Origin: Switzerland
-
Model Number: DO815 (3BSE013258R1)
-
Product Type: Digital Output Module
-
Number of Channels: 8 (1 isolated group)
-
Rated Output Voltage: 24 V DC
-
Max. Continuous Current: 2.0 A per channel (up to 12 A total per module)
-
Internal Protection: Short-circuit and over-temperature detection
-
Signal Isolation: Galvanic isolation between field and system logic
-
Interface: S800 ModuleBus
-
Weight: 0.25 kg
Features
-
High-Current Driving Capacity: Each channel handles up to 2.0A, making it ideal for driving larger solenoid valves and actuators without interposing relays.
-
Intelligent Fault Protection: Features per-channel electronic current limiting and thermal shutdown to prevent hardware damage from external electrical stressors.
-
Live System Maintenance: Fully supports hot-swap functionality, enabling rapid module exchange during active process control to minimize operational downtime.
-
Deterministic Logic Execution: Optimized for high-speed switching with minimal delay, ensuring precise coordination within the AC 800M controller environment.
-
Rugged Diagnostic Suite: Front-panel LED indicators offer immediate visual verification of channel logic states and module hardware status.
-
Enhanced System Reliability: Built-in galvanic isolation shields the central controller from field-side voltage spikes and electromagnetic interference.
