Product Details
The ABB DSTC 130 57510001-A/2, also cataloged as the DSTC 130 Communication Module, operates as a dedicated hardware component for digital data transmission and system connectivity within ABB industrial control system platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSTC 130 |
| Part Number | 57510001-A/2 |
| Brand | ABB |
| Product Type | Communication Modules |
| Origin | Sweden |
| Weight | 0.2 kg (0.44 lbs) |
| Dimensions | 100 x 50 x 20 mm |
| Operating Temp | -20 to +60 deg C |
| Power Consumption | 5 W |
| Operating Voltage | 24 VDC |
| Protection Class | IP20 |
| Connector Type | Screw terminals |
| Transmission Rate | Up to 1 Gbps |
Deterministic Network Performance and Firmware Flash Compatibility
The communication circuit assembly processes real-time fieldbus and Ethernet packet switching to deliver high-speed data transmission rates up to 1 Gbps. Built-in firmware flash compatibility allows synchronized protocol stack updates across connected control channels without disrupting local I/O density scaling. Internal filtering circuits isolate the 24 VDC supply lines and screw terminal interfaces against high-frequency backplane bus noise and electrical transients.
Frequently Asked Questions
Q: What power source is required to operate the DSTC 130 circuit board?
A: The board operates on a nominal supply of 24 VDC with a power consumption of 5 W.
Q: How are field wires attached to the DSTC 130 module?
A: Connections are secured directly to the board using integrated screw terminals.
Q: Is the DSTC 130 suitable for installation outside protective enclosures?
A: No, with an IP20 protection rating, the unit must be installed within a protective enclosure or subrack to guard against ingress of dust and moisture.
Field Installation Guidelines
- Disconnect all primary 24 VDC power sources feeding the control chassis before installing or servicing the DSTC 130 circuit board.
- Wear a grounded electrostatic discharge (ESD) wrist strap prior to removing the circuit board from its anti-static packaging.
- Align the 100 x 50 x 20 mm module within its chassis guide rails and secure it into the subrack slot.
- Insert communication and power conductors into the screw terminals and torque them appropriately to establish gas-tight electrical contact.
- Maintain a minimum distance of 200 mm between low-voltage signal cabling connected to the DSTC 130 and high-voltage power conduits to limit electromagnetic interference.
