Product Details
The ABB TC514V2 3BSE013281R1, also cataloged as the TC514V2 Communication Module, operates as a dedicated hardware component for converting Advant Fieldbus 100 electrical signals to optical fiber medium within ABB Advant Master process control networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TC514V2 3BSE013281R1 |
| Brand | ABB |
| Origin | Sweden |
| Weight | 0.34 kg |
| Dimensions | 58 mm x 168 mm x 122 mm |
| Operating Temp | Standard Cabinet Ambient (0 to 55 deg C) |
| Power Consumption | 24 VDC Control Supply |
| Interface Type | AF 100 Twisted Pair to Optical Fiber Modem / Repeater |
| Rated Isolation | 50 V |
| System Compatibility | ABB Advant Master Process Control System |
Deterministic Network Integration and Backplane Communication Velocity
The TC514V2 optical repeater converts physical twisted-pair signals to fiber media while preserving AF 100 bus communication velocity across deterministic networks. By establishing a galvanic isolation barrier rated at 50 V, the unit prevents ground loops and electrical interference from disrupting remote I/O density scaling. The module maintains full firmware flash compatibility across connected controller nodes, ensuring deterministic cycle times and synchronization across extended topology runs.
Frequently Asked Questions
Q: What power input is required to operate the TC514V2 repeater?
A: The module requires a nominal 24 VDC external control power supply for internal signal processing and optical transceiver operation.
Q: What isolation rating is provided between the electrical bus interface and internal circuits?
A: The device features a rated isolation voltage of 50 V to protect the AF 100 network segment from common-mode voltage spikes.
Q: How does switching from electrical to optical media affect network deterministic execution?
A: Optical signal conversion introduces negligible propagation delay, preserving deterministic network timing and scan cycle synchronization across AF 100 fieldbus nodes.
Field Installation Guidelines
- Disconnect external 24 VDC power before wiring electrical terminals or seating the module into the mounting assembly.
- Maintain minimum bend radius limits for fiber optic cables to avoid optical signal attenuation and packet loss.
- Ensure twisted-pair shielding is grounded at specified single-point earth terminations according to AF 100 cable installation rules.
- Mount the module vertically to facilitate natural convective heat dissipation across the enclosure.
