Product Details
The ABB SF810-FOC-PYRO-TL, also cataloged as the SF810 Flame Scanner, operates as a dedicated hardware component for optical flame signal detection and spectral discrimination within ABB combustion monitoring architectures.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | SF810-FOC-PYRO-TL |
| Brand | ABB |
| Origin | Sweden |
| Weight | 1.00 kg |
| Dimensions | 175 mm x 138 mm x 257 mm |
| Operating Temp | -20 to 70 deg C |
| Power Consumption | 24 VDC Nominal |
| Detection Technology | Optical Pyrometer / Fiber Optic Coupling |
| Enclosure Rating | Industrial Heavy-Duty Housing |
| Signal Output | Frequency / Analog Flame Intensity Output |
Deterministic Network Integration and I/O Density Scaling
The SF810-FOC-PYRO-TL scanner transmits real-time combustion intensity values to centralized safety shutdown system racks, preserving high backplane bus communication velocity across Profinet and EtherNet/IP deterministic networks. Signal processing circuits maintain dynamic filtering algorithms to filter background radiation without delaying trip sequence responses. Compact mounting geometry supports maximum cabinet I/O density scaling during multi-burner field integrations, while modular electronics ensure full firmware flash compatibility across primary burner management system modules.
Frequently Asked Questions
Q: Can the SF810-FOC-PYRO-TL optical head be removed or serviced while the central control loop is active?
A: The sensing electronics may be disconnected, provided the associated burner fuel safety shut-off valve loop is placed in a bypassed or off-line safe state.
Q: How does fiber optic coupling improve signal integrity in harsh combustion environments?
A: Fiber optic conduits isolate the primary optical sensor head from direct thermal conduction, allowing accurate light transmission to the remote processing unit without thermal drift.
Q: What grounding procedure prevents electrical noise interference on the flame intensity signal output?
A: The fiber optic sheath and sensor ground conductor must bond directly to the local panel functional earth point using short, low-impedance copper straps.
Field Installation Guidelines
- Verify that burner power sources and fuel supply lines are isolated prior to mechanical installation.
- Mount the scanner alignment assembly securely to the sight tube to align the optical axis with the target flame zone.
- Ensure fiber optic cables maintain a minimum bend radius of 100 mm to prevent signal attenuation or internal fiber fracture.
- Tighten cable gland seals to maintain ingress protection against ambient dust, moisture, and combustion air pressure.
