Product Details
The ABB PCD230A101 3BHE022291R0101, also cataloged as the PCD230A101 Excitation Controller Module, operates as a dedicated hardware component for excitation control loop processing and real-time signal processing within ABB generator excitation and drive automation systems. The assembly executes control algorithms while managing peripheral communications across onboard interfaces.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | PCD230A101 3BHE022291R0101 |
| Brand | ABB |
| Origin | Global Manufacturing Facilities |
| Weight | 1.53 kg (Net) |
| Dimensions | 73.5 mm x 142 mm x 373 mm |
| Operating Temp | -20 deg C to +60 deg C |
| Power Consumption | 24 VDC external supply |
| Onboard Memory | 128 MB to 256 MB DDR |
| Operating Systems | Windows XP, XPE, WinCE 6.0, Linux |
| Communication Ports | 1x Standard Parallel Port, 2x Serial Ports, 2x USB Ports |
| Module Type | Excitation Controller Module |
Backplane Bus Communication Velocity & I/O Density Scaling
The PCD230A101 controller module processes critical generator parameters while sustaining backplane bus communication velocity across attached system sub-racks. Its integrated memory controller and real-time operating system support streamline data throughput to minimize execution latency. Compact chassis design supports cabinet I/O density scaling, while maintaining high firmware flash compatibility across varied OS deployment options including Linux and WinCE 6.0 embedded platforms.
Frequently Asked Questions
Q: How is the primary power feed delivered to the PCD230A101 module?
A: Operating power is supplied via a nominal 24 VDC input connection wired to the module power supply terminals.
Q: What peripheral interface ports are accessible directly on the controller chassis?
A: Hardware interfaces include one standard parallel port, two serial communication ports, and two USB ports for external device interlocks and engineering connections.
Q: Can the PCD230A101 run embedded Linux or real-time operating environments?
A: Yes. The onboard hardware architecture natively supports Linux, WinCE 6.0, Windows XP, and XPE operating environments.
Field Installation Guidelines
Follow these technical steps during panel assembly and system mounting:
- Chassis Insertion: Slide the PCD230A101 module vertically along the sub-rack guide rails until the backplane connectors align, then press firmly into place.
- Fastener Securing: Tighten the top and bottom front panel retaining screws to 0.6 N-m to prevent displacement under operational vibration.
- Power Wire Termination: Connect the 24 VDC supply leads to the designated input terminals using stranded copper conductors with ferruled ends.
- Interface Shielding: Attach serial and parallel communication cables with shielded connectors, clamping the cable braid to the cabinet protective earth (PE) bus.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
