Product Details
The ABB DSTA 001B 3BSE018316R1, also cataloged as the DSTA 001B Connection Unit, operates as a dedicated hardware component for field signal termination and cable routing to the DSAX 110A analog board within ABB Advant Master Process Control System platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSTA 001B 3BSE018316R1 |
| Brand | ABB |
| Origin | Sweden |
| Weight | 0.222 kg |
| Dimensions | 540 mm x 30 mm x 335 mm |
| Operating Temp | 0 to +55 deg C (Standard Industrial Range) |
| Power Consumption | Passive Hardware Termination |
| Target Board Compatibility | DSAX 110A Analog Board |
| Product Type | Connection Unit / I-O Module |
Backplane Bus Communication Velocity & I/O Density Scaling
The connection unit facilitates physical signal passthrough from field cabling to primary controller backplanes. Optimized contact path traces preserve signal integrity across high-density I/O configurations. System-level synchronization maintains deterministic network scan execution, while physical design integrity ensures backplane bus communication velocity and firmware flash compatibility remain uncompromised throughout high-speed analog loop sampling.
Frequently Asked Questions
Q: Which analog board is designed to interface directly with the DSTA 001B termination unit?
A: The DSTA 001B is designed specifically as the physical connection unit for the DSAX 110A analog board.
Q: Does the DSTA 001B connection unit consume active backplane current?
A: No, the connection unit functions as a passive physical termination and interface board, relying on the host rack supply for signal path continuity.
Field Installation Guidelines
- Isolate field loop power and controller backplane power prior to attaching ribbon cables or wiring field connections to the unit.
- Securely mount the 540 mm chassis to panel mounting rails using standard fasteners to ensure vibration stability.
- Connect all cable shield braids directly to a low-impedance protective earth (PE) ground bar to prevent noise interference on analog signal lines.
- Verify keyed header connector alignment when connecting the ribbon harness to the DSAX 110A analog board to prevent pin bending.
