Product Details
The ABB 560ETH02 1KGT009200R0001, also cataloged as the 560ETH02 Ethernet Communication Module, operates as a dedicated hardware component for network interface bridging and Ethernet data routing within ABB RTU560 platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 560ETH02 1KGT009200R0001 |
| Brand | ABB |
| Origin | Germany |
| Operating Temp | -40 to +70 deg C |
| Power Consumption | 2 W Typical |
| Power Supply | 5 VDC via Backplane Bus |
| Communication Interface | 2 x Ethernet Network Ports |
| Target System | ABB RTU560 System Subracks |
Deterministic Network Integration and I/O Density Scaling
The 560ETH02 interface card facilitates dual-port packet switching across Profinet and EtherNet/IP deterministic networks, enabling parallel communication channels directly from the RTU backplane. Optimized internal bus decoding maintains high backplane bus communication velocity to minimize packet conversion latency during intensive telecontrol polling routines. Compact subrack form-factor design preserves I/O density scaling inside subrack frames, while onboard flash memory guarantees full firmware flash compatibility during remote system maintenance and software revision updates.
Frequently Asked Questions
Q: How does the 560ETH02 draw operational logic power inside the RTU rack?
A: Power is supplied directly at 5 VDC through the system backplane connector, consuming 2 W under typical operational loads without requiring external DC wiring.
Q: Are the two Ethernet ports on the front panel individually configurable?
A: Yes, the dual Ethernet ports support independent network node addresses to enable redundant network topologies or distinct LAN segment routing.
Q: What environmental thermal thresholds must be observed during enclosure layout?
A: Operating temperature range is -40 to +70 deg C. Adequate natural convection cooling must be maintained across the subrack slots to avoid thermal throttling.
Field Installation Guidelines
- Verify that subrack power is completely turned off before inserting or removing the 560ETH02 module from the backplane guide rails.
- Use industrial-grade shielded Category 5e or Category 6 Ethernet cables with RJ45 metal-shielded connectors.
- Ground cable shields to the main cabinet earth rail to mitigate high-frequency electromagnetic interference.
- Tighten the module top and bottom retaining screws to ensure continuous chassis grounding contact with the subrack frame.
