Product Details
Configured for optical signal conversion in NetCon 5000 network systems, the Woodward 5466-340 (5466-340 F/O Transceiver Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 5466-340 |
| Brand | Woodward |
| Origin | USA |
| Weight | Approx. 0.6 kg |
| Dimensions | Standard NetCon rack-mount module |
| Operating Temp | -20 deg C to +55 deg C |
| Power Consumption | < 10 W |
| Ports | 2 x RX, 2 x TX |
| Signal Conversion | Electrical to Optical / Optical to Electrical |
Actuator Loop Feedback Response
The 5466-340 manages the transduction of high-speed data signals between electrical backplane logic and optical transmission media. This conversion is integrated within the governor control loop to facilitate real-time telemetry exchange across extended transmission distances. The module maintains signal fidelity during conversion, ensuring that the actuator loop feedback response remains synchronized with host processor setpoints. Thermal heat sink dissipation profiles integrated into the internal module architecture ensure stability for the high-speed optoelectronic components during continuous data traffic cycles.
Frequently Asked Questions
Q: Does the 5466-340 require specific fiber optic cable types for optimal performance?
A: The module is designed for standard multi-mode or single-mode fiber interfaces as specified by the system installation requirements. Ensure the fiber core size matches the transceiver port rating to maintain low insertion loss.
Q: Is the 5466-340 capable of hot-swapping within the NetCon 5000 rack?
A: No. All power must be removed from the rack before insertion or extraction to avoid damaging the electrical backplane connector pins or the internal optical circuitry.
Field Installation Guidelines
- Power down the NetCon 5000 system and ensure all chassis power supplies are isolated.
- Clean the fiber optic connector end-faces with an approved fiber cleaning solution before insertion into the RX/TX ports.
- Slide the module into the designated rack slot, ensuring the backplane connector seats fully without force.
- Secure the front-panel mounting screws to ensure the module is properly grounded to the chassis and resistant to mechanical vibrations.
- Verify that the fiber optic cable radius of curvature exceeds the minimum manufacturer specification to prevent signal attenuation and fiber fracture.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
