Product Details
The Honeywell SC-UCMX01, also cataloged as the SC-UCMX01 Remote Terminal Unit Controller, operates as a dedicated hardware component for field data acquisition and supervisory logic processing within SCADA system architectures.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | SC-UCMX01 |
| Brand | Honeywell |
| Origin | USA / As specified on hardware label |
| Weight | (~0.85 kg) |
| Operating Temp | -40 to 70 deg C |
| Power Consumption | 24 VDC nominal supply input |
| Controller Class | Remote Terminal Unit (RTU) Controller |
| System Platform | Honeywell SCADA / ControlEdge RTU |
| Communication Ports | RS-232/485 serial and 10/100 Mbps Ethernet ports |
| Field Interfaces | Integrated high-density analog and digital I/O channels |
4-20 mA HART Loop Protocol and Channel-to-Channel Isolation
The SC-UCMX01 executes real-time field signal sampling and telemetry processing over distributed SCADA topologies. Field-side analog channels directly interface with pressure, flow, and temperature transmitters utilizing 4-20 mA HART loop protocol for simultaneous primary variable acquisition and digital device diagnostics. Integrated galvanic channel-to-channel isolation on the main processing board suppresses earth loop current circulating between remote field instrumentation sites and control room backplanes, guaranteeing signal integrity under harsh industrial EMC conditions.
Frequently Asked Questions
Q: How does the SC-UCMX01 handle field communications across remote SCADA nodes?
A: The controller features onboard Ethernet and software-configurable RS-232/485 serial interfaces supporting standard industrial telemetry protocols such as DNP3, Modbus RTU/TCP, and IEC 60870-5-104.
Q: What power input range is required for powering the SC-UCMX01 unit?
A: The SC-UCMX01 operates on a standard 24 VDC industrial power distribution rail.
Field Installation Guidelines
- Secure the SC-UCMX01 controller to a standard 35 mm DIN rail or mounting plate inside an IP54 or better rated enclosure to prevent dust and moisture ingress.
- Terminate 24 VDC main power lines using 1.5 mm2 (16 AWG) stranded wire with proper ferrule crimps, verifying correct polarity before applying power.
- Ground the controller chassis directly to the primary panel earth bus using a short, heavy-gauge copper grounding strap.
- Route serial and Ethernet communication cables in separate wiring ducts away from high-voltage AC power lines to minimize signal interference.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
