Product Details
Configured for internal bus routing and mechanical module retention in ControlWave automation systems, the Emerson 396356-01-0P (396356-01-0P Chassis and Backplane Assembly) provides direct physical/electrical execution. The panel-mount rack assembly accommodates up to 8 I/O module positions, distributing system power and internal signal communication paths across active card slots with a backplane bus power draw of 1650 mA at 12 VDC.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 396356-01-0P |
| Brand | Emerson |
| Origin | USA |
| Weight | 0.66 kg (1.45 lbs) |
| Dimensions | Standard ControlWave 8-slot chassis envelope |
| Operating Temp | -40 to +70 deg C |
| Power Consumption | 1650 mA at 12 VDC |
| System Platform | ControlWave PLC |
| Product Type | Chassis and Backplane Assemblies |
| Capacity | 8 I/O module positions |
| Mounting Style | Panel mount |
| Structure | Integrated backplane bus card cage |
4-20 mA HART Loop Protocol and Channel Isolation
The multi-slot backplane architecture delivers channel-to-channel isolation across adjacent card slots to eliminate inter-module noise coupling and differential ground potentials. Internal trace routing maintains clean signal integrity for 4-20 mA HART loop protocol pass-through communications, preventing high-frequency digital secondary variable modulation from distorting analog state values. The backplane design ensures stable power distribution and cold junction compensation references across all 8 slot positions during industrial temperature fluctuations.
Frequently Asked Questions
Q: What is the primary electrical power requirement for the 396356-01-0P backplane bus?
A: The backplane assembly requires a internal system bus supply rated at 1650 mA at 12 VDC to power connected I/O modules.
Q: Can modules be inserted or removed from the 396356-01-0P assembly while power is applied?
A: No. System power to the chassis backplane must be completely isolated before inserting or removing I/O cards to prevent edge-connector damage or electrical transients on the bus.
Q: How is the chassis grounded within a control enclosure?
A: The panel-mount chassis features dedicated grounding points that must be bonded directly to the primary enclosure earth grounding bar using low-impedance copper conductors.
Field Installation Guidelines
- Mount the chassis assembly securely onto a flat enclosure backpanel using appropriate hardware through all panel-mount slot tabs.
- Establish a low-resistance earth ground connection from the chassis frame lug to the main enclosure grounding bus bar.
- Verify that 12 VDC system power supplies are turned off before connecting power wiring to the chassis backplane power interface.
- Inspect all 8 backplane connector pins for straightness and cleanliness prior to module insertion.
- Align I/O module cards with the physical guide rails and slide them straight into position until backplane connectors seat completely.
- Route all field wiring cables separately from backplane bus lines to prevent electromagnetic interference from coupling into adjacent I/O channels.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
