CI532V04 3BSE003829R1 | ABB | Bus Card Communication Interface

Description

The ABB CI532V04 (3BSE003829R1) is a high-performance communication module engineered for Modbus data exchange within ABB Advant control systems. It provides stable RCOM and RCOM+ connectivity, ensuring consistent signal integrity and efficient data handling in distributed control environments.

Specifications

• Model: CI532V04

• Part Number: 3BSE003829R1

• Product Type: Bus Communication Interface Module

• Communication Standard: Dual Modbus (RS-485)

• Supported Protocols: RCOM and RCOM+

• System Compatibility: ABB Advant Controller Series

• Compliance: Exempt from RoHS Directive 2011/65/EU under Article 2(4)(c), (e), (f), and (j)

• Reference Document: EU Declaration of Conformity 3BSE088609

• Dimensions (W × H × D): 108 × 22.5 × 234 mm

• Net Weight: 0.155 kg

• Installation Method: Frame or rack-mounted configuration

• Power Supply: Draws directly from the system backplane

Features

• Dual Modbus Channels: Enables two independent communication paths for efficient data transfer.

• Reliable Operation: Optimized for high-speed serial communication in industrial networks.

• System Integration: Designed for seamless use within ABB Advant control platforms.

• Compact and Lightweight: Simplifies installation in space-limited control cabinets.

• Flexible Configuration: Supports redundant or independent channel setups.

• Industrial Durability: Resistant to electrical noise and mechanical stress.

• Maintenance Ease: Plug-in design allows quick replacement and service access.
