Product Details
Configured for multi-channel signal processing and clock synchronization in ABB Grid Automation and Protection IED platforms, the ABB 1MRK002133-ACr06 (1MRK002133-AC Analog Digital Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1MRK002133-ACr06 |
| Brand | ABB |
| Origin | Standard ABB Manufacturing |
| Weight | Approximately 2.0 kg |
| Dimensions | Standard Relion Chassis Slot |
| Operating Temp | -25 to +70 deg C (Standard Industrial Range) |
| Power Consumption | Backplane Bus Driven |
| Channel Count | 12 Analog Digital Conversion Channels |
| Type Designation | ADM (Analog Digital Module) |
| Feature Type | Integrated Time Synchronization |
Backplane Bus Communication Velocity & I/O Density Scaling
The analog digital module converts signals across 12 independent channels simultaneously, executing onboard time synchronization to align sampled values with system time clocks. High-speed backplane bus communication velocity allows digitized telemetry to transmit across internal backplane buses without introducing processing latency. Firmware flash compatibility across system revisions maintains deterministic synchronization and execution during I/O density scaling.
Frequently Asked Questions
Q: How many analog-to-digital conversion channels are available on the 1MRK002133-ACr06 module?
A: The module is engineered with 12 discrete channels for simultaneous analog-to-digital conversion.
Q: How does the module handle real-time signal timing across the system backplane?
A: Integrated time synchronization features align digitized analog sample frames with system clock references before data packets pass over the backplane bus.
Field Installation Guidelines
- Fully de-energize the host protection relay frame prior to inserting or removing the card from the backplane slot.
- Use an ESD grounding wrist strap during handling to shield internal analog-to-digital converter components from static discharge.
- Verify time synchronization wiring connections are properly seated to prevent timing offsets during sequence-of-events logging.
- Secure faceplate retaining screws firmly to establish proper chassis earth grounding and verify module alignment within the rack.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
