Product Details
Product Overview
The Allen-Bradley 2711-T10G20 serves as a robust human-machine interface (HMI) within the PanelView 1000 Standard series. This terminal provides centralized control and visualization for complex industrial processes via its 10.1-inch grayscale display. Although the manufacturer classifies this series as discontinued, we supply this unit as 100% Brand New original factory stock. It enables maintenance engineers to sustain legacy control architectures without undergoing the high costs and risks associated with complete system migration or software rewriting.
Technical Specifications
| Feature | Specification |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Line | PanelView 1000 Standard |
| Display Size / Type | 10.1-inch Grayscale Active Matrix TFT |
| Resolution | 640 x 480 Pixels |
| Operator Input | Analog Resistive Touchscreen (384 Cells) |
| Communication Ports | Ethernet (Base-T); RS-232 (Printer Port) |
| Input Voltage Range | 85–264V AC (47–63 Hz) |
| Application Memory | 1008 KB (Non-volatile) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Enclosure Rating | NEMA Type 12/13 or 4X (Indoor) |
| Weight | 7.00 lbs (3.18 kg) |
Engineering Advantages
-
Optimized Network Integration: The integrated Ethernet port facilitates high-speed data exchange with PLC-5, SLC 500, and ControlLogix controllers. This eliminates the need for external protocol converters and simplifies the connection to plant-wide supervisory networks.
-
Resilient Display Architecture: The 2711-T10G20 utilizes an Active Matrix TFT with a 100,000-hour LED backlight life. This combination ensures high-contrast grayscale visualization that remains legible in varied factory lighting conditions, significantly outperforming legacy CCFL-based displays in longevity.
-
Gloves-on Touch Operation: The analog resistive touchscreen features 384 distinct touch cells (24 columns x 16 rows). This resolution allows operators to trigger large buttons and complex navigation menus while wearing standard industrial safety gloves, ensuring input accuracy in harsh processing environments.
-
Rugged Environmental Protection: The front-panel design meets NEMA 4X and Type 12/13 standards. This prevents the ingress of splashing water, non-corrosive liquids, and airborne dust, making the unit ideal for food and beverage or wastewater applications.
-
Legacy Compatibility Preservation: Installing a 100% Brand New 2711-T10G20 restores factory-original performance to existing PanelBuilder32 applications. It maintains the exact physical cutout and communication handshake of the original installation, eliminating the downtime required for mechanical modifications or logic re-mapping.
FAQs
-
Can I use the RS-232 port for PLC communication?
On the 2711-T10G20, the RS-232 port functions primarily as a printer port for alarm logs and data reports. You must utilize the Ethernet port for primary communication with the controller.
-
Does this model support color graphics?
No. The 2711-T10G20 features a 4-shade grayscale display. For applications requiring 16 or 256 colors, you must utilize a PanelView 1000 Color terminal (e.g., 2711-T10C20).
-
How do I transfer my old application to this new unit?
Use a standard ATA memory card or the Ethernet port with PanelBuilder32 software. Since we provide this unit as 100% Brand New, the memory is clear and ready for your existing project files.
-
Is this a refurbished or repaired unit?
Absolutely not. We guarantee this product is 100% Brand New in original factory packaging with all internal protective seals intact. This ensures the maximum possible service life for your legacy system support.
