Allen Bradley 2711-T10C1L1 PanelView Standard 1000 Operator Interface

Product Overview

The Allen Bradley 2711-T10C1L1 functions as a high-capacity Human-Machine Interface (HMI) within the PanelView Standard 1000 family. This terminal features a 10-inch color active-matrix display, providing operators with a clear, centralized visualization point for complex industrial processes. We supply this unit as 100% Brand New and Original, specifically designed for systems utilizing Remote I/O (RIO) communication. It serves as a direct hardware solution for maintaining legacy control architectures without the need for extensive software migration or panel redesign.

Technical Specifications

The 2711-T10C1L1 integrates high-resolution visualization with robust industrial networking:

Engineering Advantages

• Optimized Remote I/O Connectivity: The integrated RIO port facilitates seamless connection to PLC-5, SLC 500, and ControlLogix systems over long distances. This protocol supports high-speed deterministic data exchange, ensuring real-time status updates and command execution across the plant floor.

• Responsive Touch Interface: The analog resistive touchscreen allows precise parameter entry and screen navigation. This interface withstands industrial conditions, responding accurately even when operators wear gloves or in environments prone to surface contaminants.

• Large-Scale Visualization: The 10-inch color display offers a significant viewing area compared to smaller HMI models. This extra space allows engineers to design detailed process mimics, multi-state indicators, and complex alarm banners that remain legible from a distance.

• Dual-Port Versatility: In addition to the RIO network, the built-in RS-232 port supports local printing or point-to-point communication. This secondary interface simplifies data logging and localized diagnostics without interrupting the primary network traffic.

• Direct 24V DC Integration: The unit utilizes a standard 24V DC input, aligning with modern industrial power standards. This eliminates the need for high-voltage AC lines inside the operator console, enhancing safety and reducing electromagnetic interference (EMI) near sensitive electronics.

FAQs

• Does this unit replace the older AC-powered PanelView models?

  Yes. If you are migrating from an AC-powered version, the 2711-T10C1L1 provides the same physical footprint and Remote I/O functionality but requires a 24V DC power source. Always verify your current power supply capacity before installation.

• What is the primary function of the RS-232 port on this RIO model?

  The RS-232 port serves primarily as a printer port or for point-to-point file transfers. It does not replace the RIO port for controller communication but adds flexibility for generating hard-copy reports or localized monitoring.

• Is this a refurbished unit since the series is discontinued?

  No. We guarantee this 2711-T10C1L1 is 100% Brand New and Original. It arrives in its original Allen Bradley factory-sealed packaging with all security seals, UPC labels, and documentation intact.

• How do I configure the Remote I/O rack address?

  You configure the RIO station address and baud rate through the HMI's internal configuration menu or via the PanelBuilder32 software. Ensure the settings match the scanner's configuration in your PLC or SLC processor.
