Product Details
Product Overview
The Allen Bradley 2711P-T15C4D2 functions as a high-performance Human-Machine Interface (HMI) within the PanelView Plus 1500 series. This unit bridges the gap between complex PLC logic and operator control, providing a massive 15-inch visualization surface for real-time monitoring of industrial processes. We supply this unit as 100% Brand New and Original, ensuring peak hardware integrity for high-stakes automation environments.
Part Number Breakdown
The 2711P nomenclature identifies the specific configuration of this terminal:
-
2711P: PanelView Plus Product Category.
-
T15: 15-inch Color Touchscreen Display.
-
C: Color Active-Matrix TFT technology.
-
4: Features RS-232, Ethernet, and USB communication ports.
-
D: 18–32V DC input power (24V nominal).
-
2: Standard Logic Module with internal memory.
Technical Specifications
This HMI offers the following engineering parameters for system integration:
| Component | Specification |
| Display Type | 15-inch Color Active-Matrix TFT |
| Resolution | 1024 × 768 pixels (18-bit color) |
| Brightness | 300 cd/m² |
| Input Method | Analog Resistive Touchscreen |
| Input Voltage | 18 to 32 V DC (24 V DC nominal) |
| Power Draw | 39 W (Typical) / 70 W (Peak) |
| Memory Expansion | Supports up to 512 MB CompactFlash |
| Communication | Ethernet 10/100Base-T, RS-232, Dual USB |
| Heat Dissipation | 240 BTU/hr |
| Clock | Battery-backed Real-Time Clock (≈4 yr life) |
Engineering Advantages
-
Superior Data Visualization: The 1024 x 768 resolution delivers crisp 18-bit graphics, allowing operators to distinguish complex alarm states and detailed P&ID diagrams at a glance.
-
Versatile Communication Stack: Integrated Ethernet and RS-232 ports facilitate simultaneous connection to legacy SLC 500 systems and modern ControlLogix networks, acting as a unified data hub.
-
Rugged Input Response: The analog resistive touchscreen responds to gloved hands and industrial styluses, ensuring reliable operation in greasy or dusty environments where capacitive screens often fail.
-
Efficient Thermal Management: This terminal dissipates 240 BTU/hr of heat. This efficiency prevents CPU throttling during high-density graphic rendering, maintaining smooth screen transitions even under heavy data loads.
FAQs
-
What is the primary power requirement for the 2711P-T15C4D2?
The module operates on a DC power range of 18V to 32V. Always use a dedicated 24V DC industrial power supply to ensure the terminal remains stable during the 70W peak startup draw.
-
Does this model support external peripheral devices?
Yes. The built-in USB host ports allow you to connect keyboards, mice, or external storage drives, simplifying data logging and onsite programming tasks.
-
How do I expand the storage for historical trending?
You can install a CompactFlash card up to 512 MB in the dedicated side slot. This allows the HMI to store extensive alarm histories and data logs without consuming the internal system memory.
-
Is this a factory-new unit?
Absolutely. We only ship 100% Brand New units in original Allen Bradley packaging. We do not sell refurbished or "New-Open-Box" stock for this series.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
