2711-NC13 | Allen-Bradley PanelView Standard Upload/Download Programming Cable

Product Overview

The Allen-Bradley 2711-NC13 serves as the primary communication link for configuring and maintaining PanelView Standard operator terminals. This high-quality RS-232 serial cable facilitates the transfer of application files between a personal computer running PanelBuilder32 software and the HMI hardware. We supply this cable as 100% Brand New original factory stock, ensuring the shielding integrity and pin-to-pin continuity required for error-free data uploads and downloads in electrically noisy industrial environments.

Technical Specifications

Engineering Advantages

• Optimized 5-Meter Reach: The 5-meter (16.4 ft) length provides ample distance for technicians to operate a laptop safely outside of high-voltage cabinet zones while connected to the HMI. This extended reach simplifies field commissioning in large-scale control suites.

• Superior EMI Shielding: The 2711-NC13 incorporates a fully shielded internal braid to protect the serial data stream from electromagnetic interference (EMI) generated by nearby variable frequency drives (VFDs) and motor starters. This prevents packet loss and "time-out" errors during critical firmware updates.

• Industrial-Grade Molded Strain Relief: Heavy-duty molded connectors prevent wire fatigue at the termination points. This rugged construction allows for frequent connection and disconnection cycles typical of portable maintenance tools used across multiple production lines.

• Null-Modem Pin Configuration: The cable utilizes a specific internal crossover (Null-Modem) wiring scheme required by the PanelView Standard communication ports. This eliminates the need for external gender changers or "null-modem" adapters, providing a direct "plug-and-play" experience.

• Gold-Plated Contacts: High-conductivity gold plating on the 9-pin connectors resists oxidation in humid or corrosive industrial atmospheres, ensuring low-resistance electrical contact over the entire lifespan of the cable.

FAQs

• Can I use the 2711-NC13 with a modern laptop that lacks a serial port?

  Yes, but you must use a high-quality USB-to-RS232 serial adapter (such as the Allen-Bradley 1203-USB or a reputable Prolific/FTDI-based converter) in conjunction with the 2711-NC13 to establish a connection.

• Is this cable compatible with PanelView Plus terminals?

  The 2711-NC13 targets the PanelView Standard (300 through 1400) series. While PanelView Plus terminals also feature RS-232 ports, they often utilize different cable configurations or Ethernet for programming. Always verify your specific HMI manual for "Upload/Download Cable" requirements.

• Does this cable support runtime communication between a PLC and HMI?

  Yes. In addition to programming, the 2711-NC13 can serve as a permanent runtime communication link between a PanelView Standard terminal and a SLC 500, MicroLogix, or ControlLogix controller via their respective RS-232 ports.

• How can I identify an original 2711-NC13 from generic imitations?

  Our 100% Brand New units feature original Rockwell Automation labeling and molded part numbers. Generic cables often lack the proper industrial shielding and specific pin-out required for reliable PanelView communication, which can lead to intermittent connection failures.
