Product Details
Configured for signal termination within the Trusted TMR system, the ICS TRIPLEX T8850 (T8850 Field Termination Assembly) provides direct physical and electrical execution. The unit functions as the primary interface between field-mounted digital instrumentation and the T8403 digital input modules, facilitating signal routing and localized power distribution for up to 40 individual channels.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | T8850 |
| Brand | ICS TRIPLEX |
| Origin | United States (US) |
| Weight | 0.8 kg |
| Dimensions | 16 cm x 16 cm x 12 cm |
| Operating Temp | Standard Industrial |
| Power Consumption | Configuration Dependent |
| Input Channels | 40 Channels |
| Operating Voltage | 24 VDC |
SIS Fail-Safe State Execution
The T8850 assembly incorporates per-channel fusing to ensure localized fault isolation, maintaining the integrity of the broader safety instrumented system (SIS). By providing galvanic isolation between field-side signals and the TMR input modules, the FTA prevents the propagation of electrical transients or short-circuit events to the primary processor. In the event of a field-side fault, the assembly ensures that the failed channel does not influence the voltage levels or signal state of adjacent channels, adhering to strict fail-safe state execution protocols required for safety-critical applications.
Frequently Asked Questions
Q: Does the T8850 support hot-swapping of connected digital input modules?
A: Yes, the T8850 utilizes a SmartSlot connection design that enables the hot replacement of associated T8403 input modules. This allows for module maintenance without requiring the disconnection of field wiring or a system-wide shutdown.
Q: How is field power integrity monitored on the T8850?
A: Each channel utilizes integrated LED indicators located on the assembly to provide visual confirmation of field power supply status. A loss of local power or a blown fuse will be indicated by the extinguished LED corresponding to the specific input channel.
Field Installation Guidelines
- Secure the T8850 assembly to a standard industrial DIN rail, ensuring the mounting clips are fully engaged for physical stability.
- Terminate 2-wire field devices directly to the designated terminals, observing proper polarity for the 24 VDC signal loop.
- Verify that all field wiring is properly shielded and routed away from high-voltage AC lines to mitigate electromagnetic interference.
- Check that the SmartSlot connection is free of debris and debris-free before inserting the T8403 digital input module.
- Ensure the grounding lug is connected to the system reference ground to facilitate surge voltage protection and signal reference stability.
- Confirm the integrity of the fuse per channel after initial power-on to ensure the circuit is active and protected.
