Product Details
Configured for distributed I/O expansion in Trusted TMR systems, the ICS Triplex T8314 (T8314 Remote Expander Chassis) provides direct physical and electrical execution. The chassis serves as the enclosure and interconnect base for remote fiber optic transceiver units, facilitating the extension of the TMR backplane bus over long distances using single-mode fiber infrastructure.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | T8314 |
| Brand | ICS Triplex |
| Weight | 5.00 kg |
| Operating Temp | Standard Industrial |
| Power Consumption | Configuration Dependent |
| Interface Requirement | 6 x Fiber Optic TX/RX units |
| Cabling Requirement | TC-302 / TC-303 interface cables |
SIS Triple Modular Redundancy (TMR) Architecture
The T8314 chassis is designed to maintain the integrity of the triple modular redundancy (TMR) 2oo3 architecture across remote locations. It supports the installation of six fiber optic transceiver units—three at each termination end—to ensure that all three redundant data paths are maintained during transmission. By providing galvanic isolation through optical fiber media, the chassis prevents ground loops and electrical interference from degrading the safety-critical data signal. This configuration supports fail-safe state execution by ensuring that the communication link between the primary controller and the remote I/O remains deterministic and protected against signal loss.
Frequently Asked Questions
Q: Are there specific requirements for the fiber optic cables used with the T8314?
A: The T8314 requires single-mode fiber optic cables. Each transceiver unit utilizes separate transmit and receive connectors to ensure full-duplex communication and synchronization between the local and remote chassis.
Q: How are the fiber optic units powered within the T8314?
A: The transceiver units are mounted on a DIN rail and are designed to accept dual power inputs. This redundant power configuration ensures that the communication link remains operational even in the event of a single power supply failure.
Field Installation Guidelines
- Secure the T8314 chassis in an environment compliant with standard industrial operating temperatures and vibration limits.
- Mount the six fiber optic TX/RX units onto the DIN rail within the chassis, ensuring dual power sources are correctly wired to each unit.
- Utilize TC-303 cables to connect the chassis interface to the transceiver units, ensuring the metal hood connectors are fully seated.
- Route single-mode fiber cables through protected conduit systems to prevent mechanical stress or fiber breakage.
- Verify optical signal levels at both ends of the transmission path using a standard light meter to ensure compliance with the manufacturer’s link budget requirements before initializing system communication.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
