Product Details
Overview
The Allen-Bradley 1762-IQ16 is a reliable 16-channel digital input module for the MicroLogix 1200 series, supporting both sink and source 24V DC signals. Designed for precise industrial control, it features low signal delay and stable operation over a wide voltage range. Compact and DIN rail-compatible, this module integrates seamlessly with MicroLogix controllers.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model Number: 1762-IQ16
-
Product Type: DC Digital Input Module
-
Voltage Category: 24V DC (sink/source)
-
Operating Voltage Range: 10–30V DC nominal; 10–26.4V DC typical
-
Number of Inputs: 16
-
Bus Current Draw (max): 70 mA @ 5V DC (0.35 W)
-
Heat Dissipation: 5.4 W @ 30V DC; 4.3 W @ 26.4V DC
-
Signal Delay (max): On: 8 ms; Off: 8 ms
-
Off-State Voltage (max): 5V DC
-
Off-State Current (max): 1.5 mA
-
On-State Voltage (min): 10V DC
-
On-State Current: 2 mA min @ 10V DC, 8 mA nom @ 24V DC, 12 mA max @ 30V DC
-
Wiring Category: 2 – signal ports
-
Dimensions (LxWxH): 8.7 × 4.1 × 9 cm
Key Features
-
16 digital input channels with selectable sink/source configuration
-
Fast 8 ms response time for both on and off signals
-
Wide operating voltage range suitable for various DC control signals
-
Compact design compatible with MicroLogix 1200 controllers
-
Low power consumption and efficient heat management
Application Scenarios
-
Digital signal monitoring and acquisition in MicroLogix-controlled systems
-
Connecting pushbuttons, switches, and low-voltage sensors
-
Automation projects requiring multiple digital inputs in a small footprint
-
Ideal for factory, process, or discrete control environments
FAQ
Q1: How many digital inputs does the 1762-IQ16 provide?
A1: The module has 16 digital input channels.
Q2: What is the typical signal delay for this module?
A2: Maximum on/off signal delay is 8 milliseconds.
Q3: Can this module handle both sinking and sourcing inputs?
A3: Yes, it supports 24V DC sink/source configuration.
