Product Details
Configured for power conditioning and DC bus distribution in DCS automation networks, the Honeywell 51307106-175 (51307106-175 Power Conditioning Power Wiring Assembly) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51307106-175 |
| Brand | Honeywell |
| Origin | USA / As specified on hardware label |
| Weight | 0.5 kg (1.1 lbs) |
| Dimensions | 22 cm x 12 cm x 5.3 cm (8.66 in x 4.72 in x 2.09 in) |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | Passive distribution board (5 A rated throughput) |
| Voltage Rating | 24 VDC |
| Current Rating | 5 A |
| Reverse Polarity Protection | Integrated diode/circuit protection against reverse polarity |
| Mounting Type | DIN rail-mounted within UIO assembly |
| Construction | Industrial-grade printed wire assembly housing |
4-20 mA HART Loop Protocol and Channel-to-Channel Isolation
The 51307106-175 power conditioning assembly delivers regulated 24 VDC power directly to field instrument loops and system I/O structures. By dampening power line ripple and voltage transients, it maintains signal integrity across attached 4-20 mA HART loop protocol field devices. Integrated reverse polarity protection prevents damage to upstream power buses, ensuring stable channel-to-channel isolation and preventing electrical noise propagation into Universal I/O (UIO) signal channels.
Frequently Asked Questions
Q: What protective mechanism does the 51307106-175 incorporate against improper field power connection?
A: The assembly features built-in reverse polarity protection to safeguard connected UIO sub-assemblies and field loops against accidental reverse wiring.
Q: What are the primary electrical voltage and current limits for the 51307106-175 board?
A: The unit operates at a nominal input/output rating of 24 VDC with a maximum continuous current capacity of 5 A.
Field Installation Guidelines
- Mount the 51307106-175 securely onto the UIO DIN rail channel inside the DCS enclosure prior to applying power.
- Connect incoming 24 VDC power wiring ensuring proper wire stripping and polarity matching to the dedicated screw terminal locations.
- Ensure all ground drain wires are terminated directly to the cabinet enclosure grounding bar to optimize transient protection performance.
- Verify total current demand through the power conditioning assembly does not exceed the maximum continuous rating of 5 A.
