Product Details
The Foxboro P0916DB, also cataloged as the P0916DB Termination Cable, operates as a dedicated hardware component for fieldbus module interface connection and signal routing within I/A Series platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | P0916DB |
| Brand | Foxboro |
| Origin | USA |
| Weight | 0.29 kg (0.65 lbs) |
| Dimensions | Length 1.0 m (Type 1 Cable) |
| Cable Type | Type 1 Prefabricated Termination Cable |
| Operating Temp | -20 to +70 deg C |
| Power Consumption | Passive (0 W) |
| Conductor Configuration | Shielded Multi-Conductor Assembly |
Channel-to-Channel Isolation & Signal Integrity
The Foxboro P0916DB termination cable maintains signal integrity across fieldbus module interfaces by providing continuous copper conductors with heavy shielding to suppress magnetic coupling and cross-talk. Compatible with 4-20 mA HART loop protocol signal paths and discrete I/O wiring, the cable preserves channel-to-channel isolation ratings specified by the attached baseplates and termination assemblies. High-density outer jacketing protects internal conductors from mechanical abrasion and ambient electrical noise in control cabinet layouts.
Frequently Asked Questions
Q: Can the Foxboro P0916DB termination cable be installed or removed while the baseplate is energized?
A: Yes, the P0916DB is a passive interface cable that supports live connection and disconnection, provided the connected field devices do not present inductive load transients during unplugging.
Q: Does the P0916DB cable require specific orientation when mating with termination assemblies?
A: Keyed connector housings prevent reversed pin alignment during physical insertion into baseplate and termination assembly headers.
Field Installation Guidelines
- Inspect connector pins and housing alignment keys on the P0916DB cable prior to installation.
- Route the 1.0 m cable assembly through dedicated low-voltage wire channels, maintaining a minimum 300 mm separation from AC power lines.
- Observe a minimum bend radius of 75 mm to prevent conductor strain and insulation degradation.
- Fully seat connectors into baseplate and termination assembly sockets, tightening thumb screws hand-tight.
- Connect cable shield drains directly to the enclosure signal ground bus bar following single-point grounding rules.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
