Product Details
The GE IS220PDOAH1AJ, also cataloged as the IS220PDOA Discrete Output Pack, operates as a dedicated hardware component for solid-state discrete switching and load driving within GE Mark VIe control platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS220PDOAH1AJ |
| Brand | GE |
| Origin | USA |
| Product Type | Discrete Output I/O Pack |
| Output Type | Solid-State Discrete (On/Off) |
| Channel Density | 8 or 16 isolated channels |
| Operating Temp | -40 to 70 deg C |
| Storage Temp | -40 to 85 deg C |
| Humidity | 5% to 95% non-condensing |
| Vibration Tolerance | 5g RMS (10 to 500 Hz) |
| Shock Resistance | 30g (11 ms half-sine) |
| EMC Standards | EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 |
| Dimensions | Standard Mark VIe pack enclosure profile |
| Weight | Standard pack assembly weight |
| Power Consumption | System backplane bus dependent |
Deterministic Networks & Firmware Flash Compatibility
The discrete output pack connects directly to terminal blocks via dual IONet Ethernet ports, ensuring deterministic network communication with the main Mark VIe controller. Internal solid-state driver circuits feature galvanic channel isolation to prevent ground fault currents from propagating across system backplane logic. Onboard microprocessors continuously verify output command states while maintaining firmware flash compatibility for online module configuration and diagnostic reporting.
Frequently Asked Questions
Q: How does the pack communicate with the central controller?
A: The module utilizes dual redundant IONet industrial Ethernet interfaces to execute real-time deterministic communication directly with controller processing units.
Q: Are outputs galvanically isolated from internal system logic?
A: Yes, each solid-state discrete output channel incorporates optical/galvanic channel isolation to shield internal logic circuits against field ground fault conditions and voltage transients.
Q: What mounting format does the module assembly support?
A: The hardware integrates a compact industrial enclosure designed for direct mounting onto DIN rail channels or secure attachment to terminal board connector headers.
Field Installation Guidelines
- Ensure panel supply power is isolated before attaching or removing the module from its matching terminal board connector.
- Snap the pack onto the DIN rail or mount securely to the terminal board header using captive panel screws.
- Connect dual Ethernet cables to the designated IONet ports to maintain network topology redundancy.
- Verify field wiring terminations on the associated terminal board, ensuring common DC control power polarity matches design drawings.
- Connect cable shielding and terminal grounds directly to the cabinet main ground copper bus bar prior to system power-up.
