Product Details
Configured for specialized signal processing and system execution in Mark VIe platforms, the GE IS210AEAAH1BDA (IS210AEAA Conformal Coated PCB) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS210AEAAH1BDA |
| Brand | GE Energy |
| Origin | USA |
| Weight | 0.45 kg |
| Dimensions | 165 x 115 x 25 mm |
| Operating Temp | -30 to 65 deg C |
| Power Consumption | 10 W |
| Board Coating | Full Conformal Coating |
| Functional Revision | Grade B |
| Mounting Type | Panel Mount via 6 insulated factory-drilled mounting holes |
| Integrated Circuits | Surface-mounted with factory-printed and component label specifications |
| System Platform | Mark VIe Wind Series |
Backplane Bus Communication and Firmware Flash Compatibility
The IS210AEAAH1BDA bypassed standard VME rack backplane configurations, utilizing direct standoff mounting via six insulated factory-drilled holes for direct enclosure integration. Interface signals route through onboard trace arrays configured for deterministic communication networks within the controller environment. Firmware flash compatibility ensures synchronized operational states across system processors without packet collision. The comprehensive conformal coating protects surface-mounted integrated circuits and solder points against micro-particulate contamination, ambient humidity, and corrosive chemical agents found in field drive enclosures.
Frequently Asked Questions
Q: How is the IS210AEAAH1BDA mounted within the control panel if it does not fit standard VME racks?
A: The board mounts directly to panel backplates using six insulated factory-drilled mounting holes and metal standoffs, bypassing traditional VME rack chassis structures.
Q: What physical feature distinguishes the IS210AEAAH1BDA from the un-coated baseline model?
A: The IS210AEAAH1BDA features a complete layer of chemical conformal coating applied over all PCB surfaces and integrated circuits to prevent atmospheric degradation.
Q: Does replacing an un-coated board with the IS210AEAAH1BDA require modifications to signal wiring?
A: The board maintains functional pinout compatibility with the base AEAA series, but physical mounting points must accommodate the direct panel standoffs instead of rack card guides.
Field Installation Guidelines
Perform all installation procedures under de-energized conditions and verify that power sources to the cabinet are fully isolated. Secure the board to the panel backplate using appropriate standoffs through the six factory-drilled insulated mounting holes to establish proper mechanical support. Connect a dedicated ESD grounding wrist strap prior to handling the board to prevent static discharge to onboard integrated circuits. Ensure all interconnecting ribbon cables and terminal harnesses are fully seated and latched to maintain signal integrity. Route low-voltage signal cables away from high-voltage drive conductors to limit inductive noise coupling.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
