IC200UEX636 | GE Fanuc VersaMax | 6-Point Analog Expansion Module

Product Description

The GE Fanuc VersaMax IC200UEX636 Analog Expansion Unit is designed to extend the analog input and output capabilities of VersaMax Micro PLC systems. With six total I/O points, this module provides flexible signal handling for both current and voltage applications, making it suitable for demanding industrial automation tasks.

Technical Specifications

• Model / Part Number IC200UEX636

• Manufacturer GE Fanuc Emerson

• Product Line VersaMax

• Product Type Analog Expansion Module

• Weight 2.00 lbs (0.91 kg)

• Total I/O Points 6 (4 inputs, 2 outputs)

• Input Ratings

• 0 to 10 VDC

• –10 to +10 VDC

• 4 to 20 mA

• 0 to 20 mA

• Output Ratings

• 0 to 10 VDC

• 4 to 20 mA

• 0 to 20 mA

• Resolution 12-bit for both inputs and outputs

• User Sensor Power Supply 200 mA at 24 VDC

• Power Voltage 120/240 VAC

• Voltage Type AC

Application Scenarios

• Expansion of analog I/O capacity in VersaMax Micro PLC systems

• Industrial processes requiring precise current and voltage signal control

• Applications involving sensors, actuators, and instrumentation with analog outputs

FAQ

Q: How many I/O points does the IC200UEX636 provide?  A: It offers 6 points in total, with 4 inputs and 2 outputs.

Q: What resolution is supported?  A: Both inputs and outputs operate at 12-bit resolution.

Q: What types of signals are compatible?  A: Current (0–20 mA, 4–20 mA) and voltage (±10 VDC, 0–10 VDC).

Q: Does the module provide sensor power?  A: Yes, it supplies 200 mA at 24 VDC for sensors.

Comparison with Similar Models

• IC200UEX636-C: 6-point analog expansion, 12-bit resolution, AC powered

• IC200ALG331: 4-channel analog output, 16-bit resolution, advanced diagnostics

• IC200UEX634: Analog expansion with different input/output ratios for specialized applications
