Product Details
Product Description
The Honeywell FC‑TSDO‑0824 TSDO‑0824 is a Safe Digital Output Field Termination Assembly (FTA) designed to provide secure and reliable digital output connections in Honeywell safety and process control systems. With eight channels, robust electrical ratings, and compliance with IEC standards, it ensures dependable performance in demanding industrial environments.
Technical Specifications
-
Model / Product No.: FC‑TSDO‑0824 TSDO‑0824
-
Manufacturer: Honeywell
-
Type: Safe Digital Output FTA
-
Number of Channels: 8
-
Maximum Voltage: 36 VDC (IEC 1010:1990, Overvoltage Category 3)
-
Continuous Current per Channel: 1.5 A (actual maximum defined by connected output module)
-
DIN EN Rail Compatibility: TS32 / TS35 × 7.5
-
Rail Length Required: 61 mm (2.40 in)
-
Screw Terminal Specifications:
-
Maximum wire diameter: 2.5 mm² (AWG 14)
-
Strip length: 7 mm (0.28 in)
-
Tightening torque: 0.5 Nm (0.37 ft‑lb)
-
Dimensions (D × W × H): 60 mm × 70 mm × 58 mm
-
Shipping Weight: ~3 kg
-
Warranty: 12 months standard coverage
Key Features
-
Safety‑Certified Output Assembly: Designed for SIL‑rated safety systems
-
Compact DIN Rail Mounting: Fits standard TS32 and TS35 rails with minimal space requirements
-
Reliable Electrical Performance: Supports up to 1.5 A continuous current per channel
-
Industrial Durability: Built for long‑term use in harsh automation environments
-
Ease of Wiring: Screw terminals with defined torque and strip length for secure connections
Application Scenarios
-
Distributed control systems requiring safe digital outputs
-
Emergency shutdown systems (ESD) in oil & gas and petrochemical industries
-
Power generation and heavy manufacturing environments
-
Safety instrumented systems requiring IEC‑compliant output assemblies
FAQ
Q: How many channels does the FC‑TSDO‑0824 provide? A: It offers 8 independent digital output channels.
Q: What is the maximum current supported per channel? A: Each channel supports up to 1.5 A continuous current, with the actual maximum defined by the connected output module.
Q: Is this module compatible with standard DIN rails? A: Yes, it supports TS32 and TS35 × 7.5 DIN rails.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
