Product Description
The HIMA F 6214 is a high-performance analog input module designed for precise measurement of voltage and current signals in industrial automation systems. With four input channels, robust isolation, and 12-bit resolution, it provides accurate signal acquisition and reliable integration into safety and control platforms.
Technical Specifications
-
Manufacturer: HIMA
-
Model: F 6214
-
Product Type: Analog input module
-
Number of Channels: 4-channel, voltage and current input options
-
Resolution: 12-bit
-
Input Voltage Range: 0–1.06 V (approx. 6% overflow)
-
Digital Conversion Values: 0 mV = 0, 1 V = 3840
-
Wait After Test: 100 ms
-
Shunt Resistor (R): 50 Ω, 0.05%, 0.125 W
-
Current Input Temperature Coefficient: < 10 ppm/K
-
Input Resistance: 1 MΩ
-
Input Filter Time Constant: Approx. 10 ms
-
Transmitter Supply: 25 V DC, 0–22 mA
-
Short Circuit Current: 25 mA
-
Load Impedance: Max. 900 Ω
-
Scan Time: Max. 100 ms for 4 channels
-
Basic Error: 0.2% at 25 °C
-
Operating Error: 0.3% up to +60 °C
-
Electrical Strength: 250 V against GND
-
Space Requirement: 4 TE
-
Operating Data:
-
5 V DC: 150 mA
-
24 V DC: 250 mA
-
Dimensions: 2.5 cm × 12.7 cm × 20.3 cm (1.0 in × 5.0 in × 8.0 in)
-
Weight: Approx. 0.1 kg (5 oz)
Application Scenarios
-
Process Control Systems: Provides accurate analog signal measurement for monitoring and regulation
-
Industrial Automation: Suitable for integration into HIMA safety and control platforms
-
High-Precision Measurement: Ensures reliable voltage and current acquisition with low error margins
-
Legacy System Support: Compatible with existing HIMA setups requiring analog input modules
FAQ
Q: How many channels does the F 6214 support? A: It supports four analog input channels.
Q: What is the resolution of the module? A: The module provides 12-bit resolution for accurate signal measurement.
Q: What is the maximum scan time for all channels? A: The maximum scan time is 100 ms for four channels.
