Product Details
Configured for complex logic execution and system communication in Series 90-30 PLC backplane architectures, the GE HE693CPU701 (HE693CPU701 CPU Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | HE693CPU701 |
| Brand | GE |
| Origin | USA |
| Category | PLC Module / Rack Processing Unit |
| Operating Voltage | 5 VDC (backplane power) |
| Processor Speed | 133 MHz |
| User Memory | 4 MB |
| Network Interface | Integrated Ethernet port |
| Communication Protocols | TCP/IP, Ethernet |
| Operating Temp | 0 to 60 deg C |
| Mounting Type | Rack-mounted (Series 90-30 rack slot) |
| Dimensions | Standard Series 90-30 module slot profile |
| Weight | 0.23 kg (0.51 lbs) |
| Power Consumption | 5 VDC backplane bus power dependent |
Ethernet Networks & Firmware Flash Compatibility
The processing unit interfaces directly with the host backplane to manage real-time control loops and distributed I/O scan cycles. Onboard firmware flash compatibility enables deterministic instruction execution while supporting network communication via integrated Ethernet TCP/IP channels. Internal backplane bus communication velocity allows simultaneous memory indexing and task execution without causing processing latencies.
Frequently Asked Questions
Q: How is operating logic power supplied to the processor module?
A: Operational power is drawn directly from the host rack backplane 5 VDC power bus rail, requiring no external supply connections.
Q: Does the processor support network communication directly on the board?
A: Yes, the module features an integrated Ethernet interface that natively executes TCP/IP communication protocols for connection to host controllers and programming software.
Q: How does the processor handle program memory and execution storage?
A: The board incorporates 4 MB of user memory allocated for program logic, dynamic data buffering, and background system configuration.
Field Installation Guidelines
- Ensure the rack power supply is completely de-energized prior to inserting or removing the processor module.
- Align the module card edges with the designated rack slot guides and seat the rear connector firmly into the backplane socket.
- Tighten the retaining screws at the top and bottom of the module frame to secure mechanical grounding and retention.
- Plug the shielded RJ45 Ethernet cable into the front panel interface, ensuring the locking tab snaps into place.
- Verify that network cabling is routed away from high-voltage field wiring and power distribution lines to prevent noise coupling.
