Product Details
Overview
The IC695NIU001 is a dedicated Ethernet Network Interface Unit (NIU) for the GE Fanuc PACSystems RX3i platform. It provides reliable network connectivity for high-speed industrial communication, supporting embedded serial communications and standard Ethernet protocols. Designed for both RX3i PCI and legacy 90-30 serial backplanes, this module ensures seamless integration in mixed-system environments. Memory retention is battery-backed, with life expectancy details available in the PACSystems NIU Reference Manual (GFK-2222).
Technical Specifications
Electrical & Power
-
Model / Part Number: IC695NIU001
-
Input Voltage: +3.3 VDC nominal, 1.25 A; +5 VDC nominal, 1.0 A
-
Power Consumption: Optimized for low power operation
-
Memory Retention: Battery-supported for CPU data preservation
Network & Communication
-
Embedded Serial Interfaces: RS-232, RS-485
-
Supported Serial Protocols: Modbus RTU Slave, SNP, Serial I/O, Modbus RTU Master via “C” block
-
Ethernet Connectivity: High-speed industrial Ethernet
Backplane & PCI
-
Backplane Support: Dual – RX3i PCI and 90-30 serial
-
PCI Compliance: Electrically compliant with PCI 2.2 standard
Mechanical & Environmental
-
Operating Temperature: 0°C to 60°C (32°F to 140°F)
-
Module Weight: 0.45 kg
-
Compact form factor for rack or chassis installation
Applications
The IC695NIU001 is suited for industrial automation tasks requiring Ethernet and serial network integration, including process control, distributed I/O systems, and real-time communication networks. It supports both new RX3i deployments and legacy 90-30 system upgrades.
FAQ / Common Questions
Q: What serial protocols are supported?
A: Modbus RTU Slave, SNP, Serial I/O, and Modbus RTU Master through “C” block applications.
Q: Can it be used in legacy systems?
A: Yes, it supports 90-30-style serial backplanes in addition to RX3i PCI.
Q: What is the operating temperature range?
A: 0°C to 60°C for normal operation.
Q: Is memory battery-backed?
A: Yes, for data retention. Refer to GFK-2222 for battery life details.
