Product Details
The Bently Nevada 3500/50-01-00 (comprising main module 288062-02 and I/O module 133442-01) is a 2-channel tachometer module designed for the 3500 Series Machinery Protection System. It accepts input signals from proximity probes or magnetic pickups to measure shaft rotative speed, rotor acceleration, and direction, comparing them against programmed alarm setpoints for monitoring and annunciation.
Ordering Option Breakdown
The model number configuration defines the hardware features and regional specifications. Option code 01 under I/O Module Type designates an I/O module with internal terminations, while option code 00 under Hazardous Area Approval Option indicates that no country-specific or additional agency approvals are required.
Inputs and Signal Processing
The module supports up to two transducer channels accepting proximity or magnetic pickup inputs across a frequency range up to 20 kHz. It provides conditioned Keyphasor signals to the 3500 rack backplane for sharing with other monitors, and features a peak hold function to record maximum shaft speed values.
Physical and Environmental Specifications
The main monitor module occupies one full-height front slot in the 3500 rack, measuring 241.3 mm x 24.4 mm x 241.8 mm with a weight of 0.82 kg. The associated internal termination I/O module occupies a matching full-height rear slot, measuring 241.3 mm x 24.4 mm x 99.1 mm with a weight of 0.20 kg.
| Parameter | Specification |
|---|---|
| Model | 3500/50-01-00 |
| Component Assembly | 288062-02 (Main Tachometer Module) + 133442-01 (Internal Termination I/O Module) |
| Brand | Bently Nevada |
| Product Type | Tachometer Modules |
| Number of Channels | 2 channels |
| I/O Module Type | I/O module with internal terminations (01) |
| Hazardous Area Approval Option | None (00) |
| Input Signal Compatibility | Proximity probes or magnetic pickups |
| Rack Space Requirements | 1 full-height front slot (monitor), 1 full-height rear slot (I/O) |
| Main Module Dimensions | 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in) |
| Main Module Weight | 0.82 kg (1.8 lb) |
| I/O Module Dimensions | 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) |
| I/O Module Weight | 0.20 kg (0.44 lb) |
| Country of Origin | USA |
Frequently Asked Questions
Q: What components are included in the Bently Nevada 3500/50-01-00 configuration?
A: This configuration combines the 3500/50M main tachometer module (part number 288062-02) with an internal termination I/O module (part number 133442-01).
Q: What transducer types are supported by this tachometer module?
A: It accepts up to two transducer input signals from proximity probes or magnetic pickups to monitor shaft speed, acceleration, and direction.
