Product Details
Overview
The 1769-IQ6XOW4 from Allen-Bradley is a CompactLogix module designed for high-performance control in automation systems. It is optimized for low power consumption while providing reliable operation in industrial environments.
Technical Specifications
-
Brand & Model: Allen-Bradley 1769-IQ6XOW4
-
Product Type: CompactLogix Controller Module
-
Current Draw: 105 mA at 5.1 V DC, 50 mA at 24 V DC
-
Maximum Heat Dissipation: 2.75 W
-
Maximum Off-State Voltage: 11 V DC
-
Shipping Weight: 1.5 kg
-
Module Compatibility: CompactLogix Control Systems
-
Installation: Rack or DIN Rail Mountable
-
Operating Environment: Industrial temperature and humidity ranges
Applications
The 1769-IQ6XOW4 is suitable for use in CompactLogix automation systems for tasks such as discrete I/O control, analog signal processing, and integration with larger PLC networks. It is ideal for both standalone applications and distributed control configurations.
FAQ
Q: What is the power requirement for the 1769-IQ6XOW4?
A: It draws 105 mA at 5.1 V DC and 50 mA at 24 V DC, making it energy-efficient for standard PLC operations.
Q: Can this module operate in harsh industrial environments?
A: Yes, it is designed for standard industrial temperature and humidity ranges with robust heat dissipation.
Q: Is this module compatible with other CompactLogix controllers?
A: Yes, it integrates seamlessly with the CompactLogix series.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
