Product Details
The Honeywell 43193285-001, also cataloged as the 43193285-001 PLC Communication Cable, operates as a dedicated hardware component for direct data link connection between a Media Access Unit (MAU) and an LCNP4 interface card within Honeywell Local Control Network (LCN) architectures.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 43193285-001 |
| Brand | Honeywell |
| Origin | USA |
| Operating Temp | -20 to +60 deg C |
| Power Consumption | Passive interconnect assembly |
| Cable Type | PLC Communication Cable (MAU to LCNP4 Card) |
| Connector Type | 15-pin female-to-female connectors |
| Shielding | High-density braid/foil EMI shielding |
| Application | LCN node backplane communication path |
Process Control and DCS Instrumentation Characteristics
The 43193285-001 communication cable maintains signal integrity across high-speed digital Local Control Network (LCN) backplane interfaces. Shielding prevents electromagnetic interference (EMI) and high-frequency common-mode noise from corrupting data packets transmitted between the LCNP4 board and the Media Access Unit. By maintaining controlled line impedance, the assembly prevents bit errors and packet loss during real-time DCS processing operations, such as transferring 4-20 mA HART loop protocol diagnostics and multi-loop temperature variables requiring accurate cold junction compensation (CJC) processing at the controller level.
Frequently Asked Questions
Q: Can the 43193285-001 cable be connected or disconnected while the LCNP4 interface card is energized?
A: Disconnecting the MAU-to-LCNP4 interface cable during active node communication causes an immediate Local Control Network node drop and communication timeout. Always halt active network processing or isolate node power prior to disconnecting 15-pin cable headers.
Q: How is shield ground continuity maintained across the 15-pin connectors?
A: Internal metallic shield braid connects directly to the grounded metal shells of the female 15-pin connectors, creating a continuous low-impedance ground circuit between the LCNP4 card frame and the Media Access Unit chassis.
Field Installation Guidelines
- Inspect the 15-pin female connector pins and outer insulation jacket for mechanical damage or contamination prior to installation.
- Align the connector face with the mating 15-pin male D-sub receptacle on the LCNP4 card and MAU interface to prevent bent pin contact.
- Tighten both integrated thumbscrews on each connector shell using a flathead screwdriver to ensure vibration-proof mating contact and continuous shield grounding.
- Maintain minimum bend radius specifications when routing through cabinet wire channels to prevent shield degradation or conductor fracture.
- Keep cable runs segregated from 230 VAC/480 VAC motor control cables and variable frequency drives (VFDs) to limit coupled electrical noise.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
