HIMA F 8627X/F8627X Communication Module | HIMatrix Network Module

Product Description

The HIMA F8627X / F 8627X is a high-performance communication module engineered for HIMatrix safety and automation networks. It provides dependable data transfer between central processing units and distributed modules, supporting robust signal integrity in demanding industrial environments. This module is optimized for fast and secure communication across digital safety systems, ensuring consistent system behavior and fault tolerance.

Its modular design allows easy integration into HIMatrix racks, offering flexible installation and maintenance while supporting multiple network protocols for versatile connectivity. The F8627X / F 8627X is ideal for applications where system reliability, data accuracy, and uptime are critical.

Technical Specifications

• Manufacturer: HIMA

• Model: F8627X / F 8627X

• Product Type: Communication Module

• Function: Provides network connectivity for HIMatrix distributed I/O systems

• Supported Protocols: PROFIBUS, Modbus, HIPRO-S V2, Ethernet (depending on system configuration)

• Input/Output Interfaces: Multiple digital interfaces for safe data transfer

• Supply Voltage: 24 V DC

• Operating Temperature: –20°C to +70°C

• Storage Temperature: –40°C to +85°C

• Mounting Options: HIMatrix rack or DIN-rail installation

• Redundancy: Supports dual-channel and fault-tolerant communication

• Dimensions (H x W x D): 35 mm x 150 mm x 125 mm (typical)

• Weight: 0.8 kg

Applications

• Network communication for HIMatrix safety and automation systems

• Data transfer between central CPUs and remote I/O modules

• Process control in oil & gas, chemical, power generation, and heavy industry

• Fault-tolerant operation in SIL 3 or SIL 2 safety applications

• Integration in complex distributed automation architectures

Installation & Usage Notes

• Ensure stable 24 V DC power supply and proper grounding.

• Install in HIMatrix racks or DIN-rail according to manufacturer guidelines.

• Configure module settings using HIMatrix engineering tools for optimized network performance.

• Regularly monitor module operation to ensure uninterrupted communication.

FAQ

Q1: Which network protocols does the F8627X support?
A1: It supports PROFIBUS, Modbus, HIPRO-S V2, and Ethernet depending on configuration.

Q2: Can it be used in redundant network setups?
A2: Yes, the module supports dual-channel, fault-tolerant operation.

Q3: Is the F8627X compatible with HIMatrix remote I/O modules?
A3: Yes, it is fully compatible with all HIMatrix distributed I/O modules.

Q4: What is the operating temperature range?
A4: The module operates safely between –20°C and +70°C.
