Product Details
Configured for high-speed network communication in control systems, the Woodward 5453-754 (5453-754 Ethernet Interface FTM) provides direct physical/electrical execution of signal termination and EMI shielding for Ethernet data transmission.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 5453-754 |
| Brand | Woodward |
| Origin | USA |
| Power Consumption | 15.0 W max (13.5 W typical) |
| Voltage | 5.0 VDC (5% tolerance) |
| Processor | PowerPC 750, 400 MHz |
| Bus Interface | 32-bit VME bus |
Backplane Bus Communication Velocity Licences
The 5453-754 utilizes a 32-bit VME bus interface to facilitate high-speed data exchange between the Ethernet network and the host controller. The integrated PowerPC 750 processor, clocked at 400 MHz, manages the communication stack, ensuring deterministic throughput required for real-time control applications. Data velocity across the backplane is optimized to align with the system's firmware capabilities. Users must ensure that the host controller’s backplane bus configuration and any associated communication licences are synchronized to support the bandwidth demands of the VME bus interface.
Frequently Asked Questions
Q: Does the 5453-754 require specific cable types to maintain signal integrity?
A: Yes, double-shielded Ethernet cables, specifically Screened Shielded Twisted Pair (SSTP), are required. The FTM is designed to terminate the cable shield to prevent signal reflections and mitigate external electromagnetic interference.
Q: Is the 5453-754 interface module hot-swappable under load?
A: Insertion or extraction of this module while the VME bus is active is generally prohibited unless specified by the host controller's installation manual. Always de-energize the rack to prevent potential bus communication errors or hardware damage.
Field Installation Guidelines
- Environmental Preparation: Ensure the installation site is free from excessive high-frequency electromagnetic noise.
- Mounting: Seat the module into the designated VME bus slot. Ensure the module is fully engaged with the backplane connectors and the front panel is securely fastened.
- Shielding and Grounding: Use only double-shielded (SSTP) Ethernet cables. The FTM will perform the shield termination; verify that the cabinet ground is connected to the chassis to provide a low-impedance path for EMI drainage.
- Wiring Segregation: Route Ethernet cabling separately from high-power AC lines or motor drive power leads to reduce the risk of noise induction on the communication network.
- Validation: After installation, verify the power supply input is stable at 5.0 VDC and check network diagnostic indicators on the host controller to confirm successful communication initialization.
