Product Description
The 1746-NR4 is a 4-channel RTD and resistance input module designed for the Allen-Bradley SLC 500 series. It provides precise analog measurement of resistance temperature detectors (RTDs) and other resistance-based sensors. The module supports a 16-bit input resolution with 14-bit output, delivering accurate signal conversion and reliable process control.
Engineered for industrial environments, 1746-NR4 features 500V isolation for one minute between the field wiring and the backplane, ensuring safe and stable operation. Its flexible update time range of 17 ms to 1.2 s allows adjustment to various monitoring and control needs.
Technical Specifications
-
Manufacturer: Allen-Bradley (Rockwell Automation)
-
Model / Part Number: 1746-NR4
-
Series: SLC 500
-
Module Type: RTD/Resistance Analog Input
-
Input Channels: 4
-
Input Resolution: 16-bit
-
Output Resolution: 14-bit
-
Backplane Current: 50 mA
-
Bandwidth: 2.62 – 65.5 Hz
-
Update Time: 17 ms – 1.2 s
-
Step Response Time: 60 ms (input), 2.5 ms (output)
-
Operating Isolation: 500 V DC for 1 minute
-
Operating Temperature: 0 – 60 °C
-
Storage Temperature: -40 – 85 °C
-
Module Compatibility: SLC 500 chassis
Key Features
-
High-precision 16-bit input conversion
-
Supports RTD sensors and resistance-based devices
-
Wide bandwidth and flexible update timing
-
Safe 500V isolation for industrial environments
-
Compact SLC 500 form factor for easy installation
Applications
-
Industrial temperature monitoring with RTDs
-
Resistance-based process measurement
-
SLC 500 series analog control systems
-
Data acquisition in automated control networks
