Product Details
Product Overview
The Allen-Bradley 1769-OB8 is a high-current digital output module designed for reliable signal switching and control in CompactLogix and compatible automation systems. It supports 18 output points, organized in four-point groups, and provides robust electrical isolation between channels and groups. The module operates with 24 VDC inputs, handles short-term surge currents up to 4 A for 10 ms, and is optimized for DIN rail or panel mounting. Its compact footprint and low heat dissipation make it suitable for distributed I/O configurations, while maintaining high reliability in industrial environments.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model: 1769-OB8
-
Product Type: High Current Output Module
-
Inputs: 18 channels (4 points per group)
-
Voltage Category: 24 V DC source
-
Operating Voltage Range: 20.4–26.4 V DC
-
Heat Dissipation (max): 2.2 W
-
Current Draw @ 5.1 V: 145 mA
-
On-State Current (min): 1 mA
-
Surge Current: 4 A for 10 ms, repeatable every 2 s
-
Isolation Voltage: Dielectric test 1200 V AC / 1697 V DC, output point to bus, group-to-group 75 V DC working (IEC Class 2 reinforced insulation)
-
Module Mounting: DIN rail or panel mount
-
Dimensions (HxWxD): 11.8 × 3.5 × 8.7 cm
-
Weight: 0.5 kg
-
Power Supply Compatibility: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
-
Max Modules per Power Supply: 8
-
Slot Width: 1
Features
-
Supports high-current digital outputs with precise switching
-
Grouped outputs for efficient wiring and signal management
-
Electrical isolation ensures safe operation and protects system integrity
-
Compact design for easy installation on DIN rails or panels
-
Compatible with multiple CompactLogix power supplies for flexible system design
Application Scenarios
-
Industrial control systems requiring high-current digital outputs
-
Distributed I/O configurations in CompactLogix environments
-
Switching of actuators, relays, and high-current field devices
-
Replacement or upgrade for existing 1769-series output modules
