Product Details
Overview
The Allen-Bradley 2711PC-T6C20D is a PanelView Plus 6 Compact Terminal designed for operator control and monitoring in industrial environments. Its compact form factor supports touchscreen operation while providing high-contrast color visualization for real-time process management.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model / Part Number: 2711PC-T6C20D
-
Product Type: PanelView Plus 6 Compact Terminal
-
Operator Input: Touchscreen
-
Display Type: Color active-matrix TFT
-
Display Size: 5.7 inches
-
Display Area: 115 x 86 mm (4.5 x 3.4 in.)
-
Resolution: 320 x 240, 18-bit color
-
Luminance: 440 cd/m² (Nits)
-
Backlight: White LED, not replaceable, minimum 25,000 hours at 25 °C
-
Touchscreen: 4-wire analog resistive, 1 million actuations, operating force 10–110 g
-
Battery: Real-time clock backed by CR2032 coin-cell, ±2 minutes/month accuracy, minimum 4-year life, field-replaceable
-
Memory: 512 MB nonvolatile flash (approx. 73 MB available for user), 256 MB RAM
-
Power Consumption: Max 15 W (0.6 A at 24V DC), Typical 9 W (0.375 A at 24V DC)
-
Input Voltage: 18–30 V DC, Class 2 / SELV / PELV power supply required
-
Dimensions (HxWxD): 15.2 x 18.5 x 6.8 cm
-
Series: PanelView Plus 6 Compact
Applications
-
Operator interface for machine control and process visualization
-
Monitoring and logging real-time industrial data
-
Integration into compact or space-constrained control panels
FAQs
Q1: Can the display handle continuous use in industrial environments?
Yes, the LED backlight is rated for a minimum of 25,000 hours at standard ambient conditions.
Q2: How much user memory is available for applications?
Approximately 73 MB of nonvolatile memory is available for user programs and HMI graphics.
Q3: Is the battery replaceable?
Yes, the real-time clock battery is field-replaceable using a CR2032 coin-cell (Cat. No. 2711P-RY2032 or equivalent).
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
