Allen Bradley 22A-A9P6N103 PowerFlex 4 Adjustable Frequency AC Drive

Product Overview

The Allen Bradley 22A-A9P6N103 provides a high-performance, space-saving solution for speed control of three-phase induction motors using single-phase input power. As a core component of the PowerFlex 4 family, this 2.2 kW (2.0 HP) drive excels in machine-level applications such as fans, pumps, and conveyors. We supply this unit as 100% Brand New and Original, featuring an integrated LED display and keypad for immediate out-of-the-box commissioning in standard industrial environments.

Part Number Breakdown

The 22A-A9P6N103 alphanumeric code defines the specific hardware configuration:

• 22A: Identifies the PowerFlex 4 Drive Series.

• A: Indicates 200–240V AC Input Voltage.

• 9P6: Specifies the 9.6 Amp current rating (2.2 kW / 2.0 HP).

• N: Designates an IP20 / NEMA UL Type Open enclosure.

• 1: Indicates a Fixed Keypad and LED Display interface.

• 0: Specifies the version without an internal CE compliant filter.

• 3: Identifies the configuration without an internal Brake Drive.

Technical Specifications

This drive converts single-phase input to controlled three-phase output with the following parameters:

Engineering Advantages

• Single-Phase Versatility: The drive accepts standard 240V single-phase power to drive three-phase motors. This eliminates the need for expensive three-phase utility installations in smaller facilities or remote pump stations.

• Zero-Stacking Installation: The design allows side-by-side mounting without clearance between drives. This feature significantly reduces the required panel width, allowing engineers to pack more control power into smaller electrical cabinets.

• Simplified Programming: The integral keypad allows for immediate parameter adjustment without external software. The drive uses the standard PowerFlex parameter structure, shortening the learning curve for maintenance personnel familiar with the Allen Bradley ecosystem.

• Effective Thermal Management: Despite its 2HP capacity, the unit maintains a compact footprint while utilizing a high-efficiency heatsink. This ensures stable operation during continuous duty cycles in temperatures up to 50 °C.

• Flexible Communication Integration: The drive includes an RS485 port as standard. This allows for multi-drop configurations and seamless integration into larger automated systems via DSI (Drive Serial Interface).

FAQs

• Can I use the 22A-A9P6N103 with a 240V single-phase motor?

  No. This drive requires single-phase input but produces a three-phase output for induction motors. It will not operate a single-phase motor.

• What mounting precautions should I take for an IP20 rated drive?

  The IP20 rating signifies an "Open Type" enclosure. You must install the drive inside a clean, dry control cabinet to protect the internal electronics from conductive dust, moisture, and corrosive vapors.

• Why does this model exclude the internal brake drive?

  The "103" configuration targets applications with low-inertia loads that do not require rapid deceleration. If your process requires high-speed stops or handles overhauling loads, consider a model with an integrated brake chopper or external braking resistors.

• Is this a genuine, factory-sealed product?

  Absolutely. We guarantee this 22A-A9P6N103 is 100% Brand New original stock. It ships in the manufacturer's original packaging with all security seals and technical documentation intact.
