Product Details
Overview
The DSQC500 (3HAC3616-1) serves as the central processing intelligence for the ABB S4C+ robot controller system. Unlike standard peripheral boards, this unit manages the core logic execution, motion planning, and system-wide synchronization required for precision industrial robotics. It is engineered to handle high-speed calculation tasks and provides the necessary communication pathways between the robot's software environment and its physical hardware execution layers.
Technical Specifications
The following parameters define the physical and operational characteristics of the DSQC500 (3HAC3616-1):
-
Product Function: Main Computer / CPU Control Board
-
System Compatibility: ABB S4C+ Controller Platform
-
Microprocessor Architecture: High-performance RISC processing for real-time motion control
-
Physical Dimensions: 186 mm x 61 mm x 60 mm
-
Net Weight: 0.50 kg
-
Manufacturing Origin: Sweden
-
Interface Connectivity: High-density backplane connectors for system bus integration
FAQ
How does this board differ from the DSQC508 or DSQC540?
The DSQC500 (3HAC3616-1) is the primary computational engine for the S4C+ "M2000" era. While the DSQC508 serves as an I/O interface and the DSQC540 acts as a safety/panel unit, the DSQC500 is where the RobotWare OS resides and executes.
What are the primary failure modes for this CPU board?
Common failure indicators include the inability to boot the system (System Failure LED), "Communication Lost with PC" errors on the TPU, or RAM parity errors during the initialization phase. Due to the age of S4C+ systems, thermal stress on the internal processors is the most frequent cause of hardware degradation.
Is specialized software required for replacement?
Yes. Since the DSQC500 (3HAC3616-1) is the main computer, a full system backup must be reloaded via the RobInstall or BaseWare utility after hardware installation to restore the robot's specific configuration and program parameters.
Component Comparison within S4C+ Systems
| Module Attribute | DSQC500 (3HAC3616-1) | DSQC335 (3HAB2241-1) |
| System Generation | S4C+ (M2000/M2000A) | S4 (Legacy) |
| Primary Role | Main System Logic / CPU | Main Computer Board |
| Boot Sequence | Flash Memory / Ethernet | Floppy / Serial |
| Form Factor | Compact Plug-in Module | Large Format VME Board |
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
