Product Details
Product Overview
The Allen Bradley 2711P-B10C22D9P serves as a high-tier visualization solution within the PanelView Plus 7 Performance family. This 10.1-inch widescreen terminal provides complex monitoring and control capabilities for large-scale automation systems. We supply this unit as 100% Brand New and Original, featuring an 18-bit color graphics display and a hybrid input interface. It integrates dual Ethernet ports to support advanced network topologies like Device Level Ring (DLR), making it the primary interface for demanding industrial environments.
Technical Specifications
The 2711P-B10C22D9P utilizes a high-resolution TFT display and robust memory architecture:
| Feature | Specification |
| Display Size/Type | 10.1-in. Color Active-Matrix TFT |
| Resolution | 800 x 480 WVGA |
| Operator Input | Analog Resistive Touch & Function Keypad |
| Communication | Two (2) 10/100 Ethernet, Three (3) USB Host |
| System Memory | 512 MB RAM / 512 MB Nonvolatile |
| Input Voltage | 24V DC (18–30V DC range) |
| Power Consumption | 50 W Maximum (2.1 A at 24V DC) |
| Backlight | White LED (50,000 hrs life) |
| Display Area | 196 x 118 mm (7.7 x 4.6 in.) |
| Weight | 6.00 lbs (2.72 kg) |
Engineering Advantages
-
Hybrid Operator Interface: This model combines a responsive analog resistive touchscreen with a physical keypad. This dual-input design ensures operators maintain control in environments where gloves, moisture, or vibration make touch-only interfaces impractical.
-
Dual Ethernet High Availability: The integrated dual Ethernet ports support Linear, Star, and Device Level Ring (DLR) topologies. DLR capability ensures the HMI maintains communication even if a single network cable fails, significantly increasing machine uptime.
-
Expanded Memory for Complex Projects: With 512 MB of RAM and approximately 80 MB of free user memory, this terminal handles large FactoryTalk View ME applications with extensive alarm logs, complex trending, and high-resolution graphic faceplates.
-
Superior Visual Clarity: The 18-bit color graphics and WVGA resolution provide crisp visualization of process data. The white LED backlight offers a minimum 50,000-hour lifespan, maintaining screen legibility throughout the machine’s lifecycle.
-
Simplified Peripheral Connectivity: Three high-speed USB host ports facilitate the direct connection of keyboards, mice, or external storage drives for rapid data offloading and localized maintenance.
FAQs
-
What is the benefit of the "Performance" series over the "Standard" series?
The Performance series, including the 2711P-B10C22D9P, supports more complex applications with unlimited screen counts and advanced networking features like DLR. It also provides a larger memory buffer for data-heavy projects.
-
Can I replace the backlight on this unit?
The 2711P-B10C22D9P utilizes a solid-state white light-emitting diode backlight that the manufacturer deems non-replaceable. However, the high-efficiency design ensures a service life of at least 50,000 hours at 40 °C.
-
Does this HMI support remote viewing?
Yes. When configured within the FactoryTalk environment, the terminal supports VNC (Virtual Network Computing) services, allowing authorized personnel to monitor the HMI screen remotely via a standard web browser or mobile app.
-
Is this unit a genuine, factory-sealed Allen Bradley product?
Absolutely. We guarantee this unit is 100% Brand New original hardware. It arrives in the original factory-sealed box with the verifiable UPC (885630844640) and all technical documentation intact.
