Product Details
Description
The ABB IIMCL01 is a specialized Communication Link Termination Board engineered for the Bailey Infi 90 and Network 90 Distributed Control Systems (DCS). This board serves as a critical junction for high-speed communication lines, providing the physical interface and impedance matching necessary for stable data transmission across the system’s communication bus. It is specifically designed to handle the interconnection of various control modules, ensuring that signal reflections are minimized and network integrity is maintained throughout the cabinet architecture.
Specifications
-
Brand: ABB Bailey
-
Model Number: IIMCL01
-
Product Type: Communication Link Termination Board
-
Series: Infi 90 / Network 90
-
Function: Signal termination and network link interfacing
-
Product Net Weight: 0.38 kg (0.84 lbs)
-
Gross Weight: 0.52 kg (1.15 lbs)
-
Dimensions: 177.8 mm x 35.6 mm x 101.6 mm
-
Compatibility: Used in conjunction with Infi 90 communication modules and backplane assemblies
Features
-
Network Stability: Provides essential termination resistors and circuitry to prevent signal degradation across long-distance communication links.
-
Passive Reliability: Built as a robust passive component to ensure maximum uptime without the risk of software or firmware failures.
-
Enhanced Signal Integrity: Designed with high-quality trace routing to maintain clean communication waveforms, essential for high-throughput DCS environments.
-
Streamlined Installation: Features standard mounting hole patterns and connector interfaces for rapid deployment within Infi 90 module mounting units.
-
Industrial Durability: Constructed with high-grade PCB materials to resist the effects of thermal cycling and industrial contaminants common in control room environments.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
