Product Details
Description
The TK801V003 3BSC950089R1 is a 0.3 m ModuleBus extension cable for short-distance connections in System 800xA. It features industrial-grade shielding to protect against EMI and a secure, vibration-resistant connector, ensuring reliable, low-latency communication for modular I/O expansion.
Specifications
-
Manufacturer: ABB
-
Model Number: TK801V003 (3BSC950089R1)
-
Product Type: ModuleBus Extension Cable
-
Length: 0.3 meters (approx. 1 foot)
-
Application: S800 I/O System expansion
-
Interface: ModuleBus
-
Shielding: Industrial-grade EMI protection
-
Connector Type: Proprietary S800 ModuleBus connectors
-
Weight: 0.08 kg
Features
-
High-Speed Data Continuity: Maintains the 1.5 Mbit/s or higher throughput required for rapid I/O updates between clusters and controllers.
-
Compact Layout Flexibility: The 0.3m length is ideal for tight rail-to-rail transitions within a single enclosure, preventing excessive cable clutter.
-
EMI Resilience: Features specialized shielding and twisted-pair construction to ensure signal stability in electrically noisy industrial environments.
-
Reliable Mechanical Connection: Equipped with high-retention connectors that prevent accidental disconnection due to mechanical vibration or thermal expansion.
-
Plug-and-Play Integration: Designed for immediate compatibility with all S800 I/O termination units and communication interfaces without configuration.
-
Industrial Durability: Outer jacket materials are selected for resistance to common industrial contaminants and varying temperatures.
