Product Details
The YOKOGAWA ADC32 S1, also cataloged as the ADC32 Contact Output Module, operates as a dedicated hardware component for 32-channel discrete switching execution within YOKOGAWA ProSafe-RS safety systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | ADC32 S1 |
| Brand | YOKOGAWA |
| Origin | Japan |
| Weight | 0.5 kg |
| Dimensions | 65.6 mm x 72 mm x 52.3 mm |
| Operating Temp | -10 to 55 deg C |
| Humidity Range | 5 to 95% RH (non-condensing) |
| Power Consumption | Not Specified |
| Channel Count | 32 isolated channels |
| Output Type | Relay contacts (sink/source capable) |
| Status Indication | LED status indicators per channel (on/off state) |
| System Compatibility | YOKOGAWA ProSafe-RS Safety System |
Channel-to-Channel Isolation and Safety System Integration
The ADC32 S1 provides channel-to-channel galvanic isolation across all 32 discrete output paths to suppress common-mode electrical noise and prevent signal cross-talk within control loops. Each relay contact channel features sink and source current capabilities to drive external control voltages for field actuators, interlocks, and alarm devices. Integrated LED indicators on the front panel provide channel-level status verification during system operation alongside 4-20 mA HART loop protocol sub-assemblies.
Frequently Asked Questions
Q: What channel capacity and electrical isolation configuration does the ADC32 S1 module provide?
A: The module contains 32 output channels with channel-to-channel isolation to prevent electrical interference between independent field circuits.
Q: Does the ADC32 S1 support current sinking and current sourcing wiring methods?
A: Yes, the output circuitry accommodates both sink and source configurations for compatibility with varied field loads and control voltage supplies.
Q: How is individual output channel activity monitored on the module hardware?
A: Front-panel LED status indicators correspond to each of the 32 channels to display real-time discrete on/off states.
Field Installation Guidelines
De-energize all field and rack power sources prior to installing or removing the ADC32 S1 card. Use a grounded wrist strap to prevent electrostatic discharge when handling the unit. Align the module with the rack slot guides and insert until the rear backplane interface is seated, then tighten retaining screws to verify mechanical stability and frame ground connection. Route discrete load wiring separately from high-voltage lines and analog signal cables. Ensure field cable shields are bonded to a single earth ground terminal inside the enclosure.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
