Product Overview
The Honeywell MC-DDOY22 (PN: 80363975-150) functions as a high-density Digital Output (DO) processor within the Honeywell Experion PKS and TDC 3000 architectures. This module commands 32 discrete output channels, facilitating the precise control of solenoids, relays, and motor starters. We supply this unit as 100% Brand New and Original, ensuring your industrial process control system maintains maximum uptime without the risks associated with remanufactured parts.
Technical Specifications
| Feature | Specification Details |
| Model Number | MC-DDOY22 / MC-PDOY22 |
| Part Number | 80363975-150 |
| Output Capacity | 32 Discrete Channels |
| Load Voltage (FTA OY22/62) | 15–30 Vdc |
| Max Load Voltage (FTA OY23/63) | 250 Vac / 125 Vdc (Requires 2 FTAs) |
| IOP Type | Digital Output (DO) |
| Shipping Weight | 1.5 kg (3.3 lbs) |
| Condition | 100% Brand New Original |
Engineering Advantages
-
Scalable Power Interfacing: The MC-DDOY22 adapts to diverse voltage requirements via Field Termination Assemblies (FTAs). Use the OY22/62 for low-voltage DC applications or deploy the OY23/63 to switch high-voltage AC/DC loads up to 250V, eliminating the need for external interposing relays in many configurations.
-
High-Density Rack Efficiency: This module drives 32 independent field devices while occupying a single slot in the I/O rack. This density reduces the total footprint of the control cabinet and simplifies internal bus wiring.
-
Robust Signal Isolation: The processor architecture separates sensitive logic-side electronics from field-side electrical noise and back-EMF. This protection ensures that inductive load switching does not interfere with the stability of the central controller.
-
Streamlined Troubleshooting: Integrated diagnostics monitor the health of the output processor. The DCS identifies channel-specific faults immediately, which allows maintenance teams to pinpoint failed field devices without manual loop testing.
-
Simplified Spare Parts Management: This unit serves as a universal replacement in various Honeywell I/O configurations, reducing the inventory overhead for multi-generational plants running both legacy and modern software.
FAQs
-
How does this module handle 32 outputs at high voltages?
When driving high-voltage loads (up to 250Vac/125Vdc), the system requires two OY23 or OY63 FTAs. This setup provides sufficient terminal spacing and electrical isolation to handle the increased thermal and electrical stress of high-power switching.
-
Can I hot-swap the MC-DDOY22 during operation?
Yes, this module supports hot-swapping within authorized Honeywell I/O carriers. Always follow specific plant safety protocols and ensure the replacement unit matches the hardware revision of the existing configuration to maintain continuous logic execution.
-
Is this unit compatible with older TDC 3000 systems?
The 80363975-150 processor integrates seamlessly with both legacy TDC 3000 High-Performance Process Managers (HPM) and modern Experion PKS controllers, provided the appropriate I/O link and FTA are in place.
-
Does the product arrive in original factory packaging?
We guarantee that every MC-DDOY22 unit arrives 100% Brand New in original Honeywell factory packaging. This ensures the hardware has never been deployed and meets all original manufacturer performance specifications.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
