Product Details
Configured for emergency trip solenoid power distribution in Mark VIe turbine control platforms, the GE IS200TRPGH1B (IS200TRPGH1B Terminal Board) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS200TRPGH1B |
| Brand | GE |
| Origin | USA |
| Power Consumption | Passive (Solenoid loop distribution) |
| System Role | Turbine Primary Trip (TRPG) interface |
Industrial Control and Drives Characteristics
The IS200TRPGH1B functions as the negative-side power termination interface for emergency trip solenoid circuits within the Mark VIe architecture. Operating in tandem with the TREG terminal board, it facilitates the switching logic required for overspeed protection and emergency shutdown sequences. The board supports the integration of three emergency trip solenoids, with power path management controlled by the associated I/O packs. This architecture allows for deterministic trip execution, ensuring that the control signals processed by the PPRO packs are correctly converted into state changes for the solenoid loops. The board is designed to interface via D-type connections and molded plug cables to maintain signal path integrity under high-demand turbine operational profiles.
Frequently Asked Questions
Q: Can the IS200TRPGH1B be used independently of the TREG terminal board?
A: No. The TRPG board acts as the negative-side supply interface, while the TREG board provides the positive-side power and relay switching logic. Both boards must be configured as part of the unified emergency trip loop to operate the trip solenoids.
Q: What is the significance of the solenoid groups on this terminal board?
A: The board supports three groups of solenoid logic, coordinated with the I/O pack to provide triple modular control over the trip solenoids. This arrangement ensures that the emergency trip function is maintained even if a single control path or relay group fails.
Field Installation Guidelines
- Wiring Integrity: Ensure all connections to the solenoid loops are terminated using high-quality ring or spade lugs. Confirm that negative-side conductors are tightly fastened to prevent high-resistance connections which could impede solenoid engagement.
- Cable Routing: Use shielded cables for all field wiring to minimize electromagnetic interference. Keep solenoid trip circuit wiring separate from non-trip related analog or digital input cabling to maintain physical isolation.
- Grounding: Verify that the turbine control cabinet grounding system is properly bonded to the board chassis to ensure a stable reference for the DC power loops.
- Mechanical Mounting: Install the board on the designated rail or mounting plate within the Mark VIe cabinet. Verify that the mounting hardware is tightened to the specified torque to prevent vibration-induced loosening during turbine operation.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
