Bently Nevada 3500/15-02-02-01 High Voltage AC Power Supply
Bently Nevada 3500/15-02-02-01 High Voltage AC Power Supply
Bently Nevada 3500/15-02-02-01 High Voltage AC Power Supply

Bently Nevada 3500/15-02-02-01 High Voltage AC Power Supply


Only 10 left - Selling fast

PRODUCT SKU : 3500/15-02-02-01

PRODUCT TYPE : Power Supply Modules

PRODUCT VENDOR : Bently Nevada


  • 100% Genuine Parts – Risk-Free 30-Day Returns
  • 1-Year Warranty & Expert Support for Every Order

Product Details

The 3500/93-07-01-02-00 / 3500/15-02-02-01 is a dual-slot legacy high-voltage AC power supply configuration designed for the Bently Nevada 3500 Machinery Protection System. Operating as a half-height module set installed on the left side of the 3500 rack, it converts high-voltage AC mains power into regulated operating voltages required by downstream monitoring modules. This specific model comes equipped with high-voltage AC modules in both top and bottom slots, paired with CSA / NRTL / C Class 1, Division 2 agency approvals.

Redundant Power Configuration and Slots

The ordering option digits define a fully populated, redundant power architecture:

  • Top Slot (-02): High Voltage AC supply option (175 to 264 VAC rms) serving as the secondary or backup power supply module.
  • Bottom Slot (-02): High Voltage AC supply option (175 to 264 VAC rms) serving as the primary power supply module.
  • Agency Approval (-01): CSA / NRTL / C certification rated for Class 1, Division 2 hazardous area installations.

When both power supply slots are populated, either module is capable of powering a fully loaded 3500 rack independently. If the primary supply drops power, the secondary supply seamlessly maintains system operation without interrupting monitoring functionality. Hot-swapping is fully supported, allowing maintenance staff to insert or remove a single power supply module without disrupting active rack operations.

Electrical Requirements and Compatibility

This legacy High Voltage AC module pair requires a nominal input voltage of 220 VAC across a frequency range of 47 to 63 Hz. It operates within a standard input voltage range of 175 to 264 VAC rms (247 to 373 VAC pk) and draws a maximum full-rack current of 2.3 A rms. Note that legacy installations utilizing AC Power Input Modules (PIM) prior to Revision R or AC Power Supply Modules prior to Revision M require an input voltage range of 175 to 250 VAC rms.

Parameter Specification
Model 3500/15-02-02-01
Brand Bently Nevada
Product Type Power Supply Module
Top Slot Option High Voltage AC (-02)
Bottom Slot Option High Voltage AC (-02)
Agency Approval Option CSA / NRTL / C Class 1, Division 2 (-01)
Nominal Input Voltage 220 VAC
Input Voltage Range 175 to 264 VAC rms (247 to 373 VAC pk)
Legacy Revision Requirement 175 to 250 VAC rms (PIM < Rev R / Module < Rev M)
Input Frequency 47 to 63 Hz
Full Rack Current Draw 2.3 A rms maximum
Module Dimensions 120.7 × 50.8 × 251.5 mm (4.75 × 2.0 × 9.9 in)
Module Weight 1.39 kg (3.06 lb)

Frequently Asked Questions

Q: What input voltage is required for the Bently Nevada 3500/15-02-02-01 power supply?

A: The standard high-voltage AC supply accepts 175 to 264 VAC rms (220 VAC nominal) at 47 to 63 Hz. For legacy modules prior to Revision M or PIMs prior to Revision R, the acceptable range is 175 to 250 VAC rms.

Q: How does power redundancy function in the 3500/15-02-02-01 configuration?

A: Both the top and bottom slots are equipped with high-voltage AC supplies. Either supply can independently power a full 3500 rack, allowing seamless backup and live hot-swapping without disrupting rack operations.

Q: What hazardous area certification does the -01 suffix represent?

A: The -01 agency approval suffix indicates CSA / NRTL / C certification for Class 1, Division 2 environments.
