Product Details
The 3500/15-07-07-00 is a dual Low Voltage DC power supply module manufactured by Bently Nevada for the 3500 Machinery Protection System. Installed on the left side of the 3500 rack, it converts DC power source inputs into regulated direct current operating voltages required by downstream machinery protection and monitoring cards. This specific configuration features redundant low-voltage DC supplies in both slots without specialized agency certifications.
Redundant Power Supply Configuration
The module configuration ordering options define a fully populated, dual-redundant DC power architecture:
- Top Slot (-07): Low Voltage DC supply module acting as primary or secondary power input.
- Bottom Slot (-07): Low Voltage DC supply module acting as secondary or primary power input.
- Agency Approval (-00): Standard option supplied without specific agency approvals.
When both power supply slots are populated, either module can independently power a fully loaded 3500 rack. Should one supply experience power loss or failure, the remaining unit seamlessly supports total system current draw without interrupting critical vibration monitoring or protection logic.
Physical Design and Mechanical Characteristics
The power supply module is built in a compact form factor, measuring 25.15 cm in length, 5.08 cm in width, and 12.07 cm in height. Manufactured in the USA, the complete unit has a shipping weight of 3 kg. Live hot-swapping is supported when operating in a dual-supply setup, allowing maintenance personnel to extract or replace a single card without powering down the rack.
| Parameter | Specification |
|---|---|
| Model | 3500/15-07-07-00 |
| Brand | Bently Nevada |
| Product Type | Power Supply Module |
| Top Slot Option | Low Voltage DC Supply (-07) |
| Bottom Slot Option | Low Voltage DC Supply (-07) |
| Agency Approval | None (-00) |
| Country of Origin | USA |
| Dimensions (L × W × H) | 25.15 × 5.08 × 12.07 cm |
| Shipping Weight | 3 kg |
Frequently Asked Questions
Q: What power input type is configured on the Bently Nevada 3500/15-07-07-00 module? A: Both the top and bottom slots are populated with Low Voltage DC power supply units (-07 option).
Q: Does the 3500/15-07-07-00 support power supply redundancy? A: Yes, because both supply slots are installed, either module can independently power a full 3500 rack, enabling seamless live hot-swapping during maintenance.
Q: What agency approvals are included with the -00 suffix? A: The -00 suffix indicates standard manufacturing compliance without specialized agency or hazardous area certifications.
