Product Details
Product Overview
The Allen-Bradley 1785-L40B serves as a high-performance central processing unit within the legendary PLC-5 platform. This PLC-5/40 standard processor manages complex automation tasks by coordinating extensive I/O networks through its integrated communication interfaces. It supports up to 48 Kilowords of user memory and handles massive I/O densities, making it a cornerstone for large-scale industrial manufacturing and process control. We supply this unit as 100% Brand New and Original, ensuring your legacy infrastructure maintains peak execution speeds and data integrity without the risks of refurbished hardware.
Technical Specifications
The 1785-L40B combines high-speed logic execution with versatile networking capabilities to manage distributed control systems.
-
Manufacturer: Allen-Bradley / Rockwell Automation
-
Product Line: PLC-5
-
Processor Type: PLC-5/40 Standard Processor
-
User Memory: 48 Kilowords (Battery-Backed Static RAM)
-
Total I/O Capacity: 2048 (Any mix) or 2048 Input + 2048 Output (Complementary)
-
Embedded Communication: 4 DH+/Remote I/O ports; 1 Serial port (RS-232, RS-423, RS-422A)
-
I/O Scan Time: 3 ms at 230.4 kbits/s; 7 ms at 115.2 kbits/s; 10 ms at 57.6 kbits/s
-
Backplane Current Load: 3.3A @ 5V DC
-
Power Dissipation: 17.3 Watts
-
Memory Backup: EEPROM Option (1785-ME16 to -M100)
-
Battery Type: 1770-XYC
-
Operating Temperature: 0 to 60 °C (32 to 140 °F)
-
Weight: 3.00 lbs (1.36 kg)
Engineering Advantages
-
High-Density I/O Management: The 1785-L40B controls up to 32 universal remote I/O chassis per link. This massive expansion capability allows engineers to consolidate control over expansive production lines into a single processor, reducing hardware overhead and simplifying data synchronization.
-
Deterministic Communication: Integrated Data Highway Plus (DH+) and Remote I/O (RIO) ports facilitate high-speed, deterministic data exchange. By selecting the 230.4 kbits/s transmission rate, the processor achieves a rack scan time of just 3 ms, providing the rapid response required for high-speed packaging and assembly logic.
-
Robust Memory Protection: The processor utilizes battery-backed Static RAM to prevent data loss during power cycles. For mission-critical permanent storage, it supports EEPROM modules (up to 100K words), allowing for instant program recovery and safeguarding against long-term battery depletion.
-
Multi-Standard Serial Connectivity: A single configurable serial port supports RS-232, RS-422A, and RS-423 standards. This eliminates the need for external signal converters when interfacing with legacy weigh scales, barcode readers, or non-Rockwell HMI terminals.
-
Environmental Compliance: The module meets IEC 60068-2-14 standards for thermal shock. It operates reliably in environments with rapid temperature fluctuations, ensuring consistent logic execution in unconditioned industrial cabinets.
FAQs
-
Which power supplies are compatible with the 1785-L40B?
The processor requires the 1771-P4S, 1771-P6S, 1771-P4S1, or 1771-P6S1 power supply modules. Ensure the power supply provides sufficient current for the 3.3A backplane load of the processor plus any additional I/O modules in the local chassis.
-
How do I backup the program without relying solely on the battery?
You can install an optional EEPROM module, such as the 1785-ME64 or 1785-M100. This non-volatile memory stores a master copy of your project, allowing the processor to reload the application automatically if the 1770-XYC battery fails.
-
Can the 1785-L40B function as both a scanner and an adapter?
Yes. The embedded communication ports are highly flexible. You can configure the DH+/Remote I/O ports to function as a Scanner (to control remote I/O racks) or as an Adapter (to appear as an I/O station to another master processor).
-
Is this a refurbished or surplus unit?
We guarantee this 1785-L40B is 100% Brand New and Original. It ships in factory-sealed packaging with the authentic UPC (612598124015), ensuring you receive a processor with zero operating hours and full hardware longevity.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
