Product Details
The Triconex 2201 is a communication module baseplate designed to provide mechanical mounting and backplane bus connectivity within Tricon safety instrumented systems. It functions as the physical and electrical foundation for Triconex communication modules, ensuring structured signal routing and stable power distribution to support fault-tolerant communication across control networks.
Backplane Integration and Power Distribution
The baseplate features a multi-layered backplane architecture designed for high-speed data bus traffic between communication modules and the main processor framework. It includes integrated power distribution pathways configured for dual-redundant power supplies, providing continuous operational power if a single power rail fails. The module mounting points also support online module replacement (hot-swapping) to facilitate system maintenance without disrupting system logic execution.
Installation Guidelines
- Mount the baseplate in a clean, dry, and vibration-dampened cabinet enclosure.
- Power down the system prior to inserting or removing communication modules to prevent arcing or data interference.
- Verify that all grounding straps are firmly connected to the cabinet chassis to ensure EMI shielding integrity.
- Inspect redundant power supply connections to confirm voltage stability before system commissioning.
- Maintain sufficient ventilation clearance around the baseplate to allow proper heat dissipation in high-density rack setups.
| Parameter | Specification |
|---|---|
| Model | 2201 |
| Brand | Invensys Triconex |
| Product Type | Communication Module Baseplates |
| Operating Temperature | -20 to 60 deg C |
| Net Weight | 3.2 kg |
Frequently Asked Questions
Q: Is the Triconex 2201 baseplate compatible with all Tricon modules?
A: The 2201 is specifically engineered for Triconex communication modules; compatibility with specific system revisions should be verified against hardware manual specifications.
Q: Does the 2201 baseplate support dual-redundant power supplies?
A: Yes, it features integrated power routing pathways designed to accommodate dual-redundant power supplies for continuous operation.
