Product Details
Product Description
The 140NOE77100 from Schneider Electric is an Ethernet network TCP/IP module designed for the Modicon Quantum automation platform. It provides reliable, high-speed communication between Ethernet networks and Modicon I/O systems, supporting Modbus TCP messaging and I/O scanning for seamless industrial integration.
Engineered for demanding industrial environments, the 140NOE77100 offers transparent communication, web server access, integrated diagnostics, and hot standby redundancy. Its dual interface—fiber optic MT/RJ and twisted pair RJ45—ensures versatile network connectivity.
Features
• Communication Protocol: Ethernet Modbus TCP/IP for industrial data exchange
• Network Interfaces: MT/RJ 100BASE-FX fiber optic, RJ45 10/100BASE-TX twisted pair
• Web and Diagnostics: Integrated web server, Rack Viewer, predefined diagnostic pages, Data Editor via PC
• Redundancy: Hot standby redundant architecture for high availability
• Status Indicators: Multiple LEDs for link, collision, download, fault, RUN, full-duplex, Ready, Active, Tx/Rx
• Power Supply: Powered directly from the rack; current consumption 750 mA at 5 V DC
• Compliance: CE marked, cUL, UL 508, FM Class I Division 2, CSA C22.2 No. 142
• Sustainability: RoHS/REACh compliant
Specifications
• Product Range: Modicon Quantum automation platform
• Module Type: Ethernet network TCP/IP communication module
• Transmission Rate: 10/100 Mbit/s
• Module Format: Standard, rack-mounted
• IP Protection: IP20
• Operating Temperature: 0…60 °C (32…140 °F)
• Storage Temperature: -40…85 °C (-40…185 °F)
• Relative Humidity: 95% without condensation
• Operating Altitude: ≤ 4500 m (14763 ft)
• Dimensions: Standard module dimensions
• Net Weight: 0.345 kg
Applications
The 140NOE77100 module is ideal for connecting Modicon Quantum controllers to Ethernet networks, enabling centralized monitoring, remote I/O access, and efficient Modbus TCP communication. It is suitable for industrial automation, process control, and distributed data acquisition systems requiring reliable and redundant network communication.
FAQ
Q: What type of networks does the 140NOE77100 support?
A: It supports Ethernet TCP/IP networks and Modbus TCP messaging for industrial applications.
Q: Is the module redundant?
A: Yes, it includes a hot standby redundant architecture for continuous operation.
Q: What interfaces are available on this module?
A: It features MT/RJ 100BASE-FX fiber optic and RJ45 10/100BASE-TX twisted pair connections.
